Renault 103-14 TX

Last Updated: June 2024

Overview

The Renault 103-14 TX is a versatile row-crop tractor, equipped with a four-wheel-drive MFWD 4WD chassis that enhances traction and improves mobility in a variety of field conditions. Its robust construction includes a turbocharged, liquid-cooled, four-cylinder diesel engine manufactured by MWM, designated as the TD226-4 model with a 253.6 cubic inch displacement. The engine delivers a reliable 91.2 horsepower at a rated RPM of 2350, capable of handling demanding tasks. The tractor features a synchronized transmission system with the ability to switch to a creeper setting, offering 12 standard gears and an additional 4 for each setting, resulting in 16 forward and reverse gears. This provides operators with a broad range of speeds suitable for precise fieldwork. Accommodating both standard and optional agricultural tires, the 103-14 TX supports a variety of tire setups for different conditions, while maintaining a considerable operating weight of 10849 lbs. Practical in its design, this model holds potential for a range of agricultural applications.
Show more...

Key Specifications

Category: Row Crop

Power Output: 91.2

Transmission: Synchronized, Creeper

Drive Type: 4WD

Operating Weight: 10849

Fuel Type: Diesel

Renault 103-14 TX vs. Similar Tractors

Power Output
Below Average
Greater than 16% of similar tractors.
Operating Weight
Average
Greater than 39% of similar tractors.

Technical Specifications

Engine

Manufacturer
MWM
Model
TD226-4
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
253.6
Bore (in)
4.134
Stroke (in)
4.724
Rated RPM
2350
Power Output (hp)
91.2

Transmission

Type
Synchronized, Creeper
Forward Gears
16
Reverse Gears
16
Total Gears
-

Dimensions

Length (in)
169.3
Width (in)
79.9
Height (in)
111
Operating Weight (lb)
10849

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
28
Front Tire Width (in)
14.9
Rear Tire Diameter (in)
38
Rear Tire Width (in)
16.9
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
Rear Type II
Hitch Category
II
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric (12 volts)
Brake Type
-
Hydraulic System Type
-
