Oliver 2155

Last Updated: June 2024

Overview

The Oliver 2155 is a row-crop tractor that was manufactured by the Oliver company. It features a 4x2 2WD chassis and is powered by a Minneapolis-Moline engine, available in two fuel type variants - a 9.6L 6-cylinder diesel or an 8.3L 6-cylinder LP gas. This tractor is equipped with a two-speed power shift transmission, offering 10 forward and 2 reverse gears. Its power steering and large wheelbase (104.25 inches) enhance maneuverability on the field. The large disparities in engine displacement and rated RPM between the diesel and LP gas models suggest significant differences in their designed use and performance. With an operating weight of 12,050 lbs and a length of 168.5 inches, this tractor is built for substantial work and durability. Specific details around its power output, manufacture years, and hydraulic system give insights into its operational capabilities and utility in the agricultural sector.

Key Specifications

Category: Row Crop

Transmission: Two-speed power shift

Drive Type: 2WD

Operating Weight: 12050

Fuel Type: Diesel or LP gas, depending on the engine variant

Image Gallery

Oliver 2155 Tractor

Oliver 2155 vs. Similar Tractors

Operating Weight

Average

Greater than 47% of similar tractors.

Technical Specifications

Engine

Manufacturer: Minneapolis-Moline
Model: -
Cooling Type: -
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel or LP gas, depending on the engine variant
Induction Type: Naturally aspirated
Cylinders: 6
Displacement (ci): 585 (for diesel), 504 (for LP gas)
Bore (in): 4.75 (diesel), 4.625 (LP gas)
Stroke (in): 5.50 (diesel), 5.00 (LP gas)
Rated RPM: 2200 (diesel), 1800 (LP gas)
Power Output (hp): -

Transmission

Type: Two-speed power shift
Forward Gears: 10
Reverse Gears: 2
Total Gears: -

Dimensions

Length (in): 168.5
Width (in): 95
Height (in): Unknown, highest known point is exhaust at 99 inches
Operating Weight (lb): 12050

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x2 2WD
Drive Type: 2WD
Steering Type: Power
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): Unknown based on wheel size provided (7.50x18, 7.50x16)
Rear Tire Diameter (in): -
Rear Tire Width (in): Unknown based on wheel size provided (18.4x38, 20.8x38)
Front/Rear Rim Diameter (in): 18 (front), 38 (rear)
Tire Type: Ag (Agricultural)
Manufacture - End Year: -
Hitch Type: Unknown, but rear type III/II is known which commonly indicates a three-point hitch
Hitch Category: III/II
Hitch Position: -
Hitch Capacity (lb): -
Operator Station Type: -
Starter Type: Electric starter based on the starter volts information
Brake Type: -
Hydraulic System Type: Open center
