Oliver 1870

Last Updated: June 2024

Overview

The Oliver 1870, with its distinctive green and yellow livery, is a classic example of a two-wheel drive (2WD) tractor. Outfitted with a substantial 451 cubic inch, six-cylinder Minneapolis-Moline diesel engine, this tractor boasts a substantial power plant. The three-range power shift transmission provides a considerable range of operational flexibility, offering 18 forward gears and 6 in reverse. Supported by a wheelbase of 111 inches, the Oliver 1870 offers a stable platform for a variety of agricultural tasks. Hydrostatic power steering aids in maneuverability, while its 11,900-pound operating weight suggests a strong and durable machine capable of enduring demanding farm work. The tractor is equipped with agricultural tires, with front and rear tread widths adjustable to suit different working conditions. The lack of information on specifics like power output, length, width, and height precludes an exhaustive description, but it was clearly designed to tackle substantial farming operations with reliability.
Show more...

Key Specifications

Transmission: Three-range power shift

Drive Type: 2WD

Operating Weight: 11,900

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Minneapolis-Moline
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
6
Displacement (ci)
451
Bore (in)
4.375
Stroke (in)
5
Rated RPM
1800
Power Output (hp)
-

Transmission

Type
Three-range power shift
Forward Gears
18
Reverse Gears
6
Total Gears
-

Dimensions

Length (in)
-
Width (in)
-
Height (in)
-
Operating Weight (lb)
11,900

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
Category II
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
