Oliver 1465

Last Updated: June 2024

Overview

The Oliver 1465 is a utility tractor that was built to provide reliable service for a variety of agricultural tasks. It is powered by a 77 horsepower, liquid-cooled diesel engine with direct injection, boasting a displacement of 278.3 cubic inches. The tractor operates on a 4x2 2WD chassis and is controlled through power steering for ease of maneuverability. A gear-driven transmission offers 7 forward and 2 reverse speeds. The 1465 model rides on ag tires with a shipping weight of 6700 pounds. It features a three-point hitch with a category I/II configuration, primarily for rear attachments, and an electric starting system. The tractor’s dimensions include a length of 140 inches and a height at the steering wheel of 68.8 inches. Note that some specifics such as the manufacture start and end years, tire dimensions, hitch lift capacity, and hydraulic system type remain unspecified in the provided data.

Key Specifications

Category: Utility

Power Output: 77

Transmission: Gear

Drive Type: 2WD

Operating Weight: 6700

Fuel Type: Diesel

Image Gallery

Oliver 1465 Tractor

Oliver 1465 vs. Similar Tractors

Power Output

Average

Greater than 69% of similar tractors.

Operating Weight

Average

Greater than 51% of similar tractors.

Technical Specifications

Engine

Manufacturer: Unknown
Model: OM C03/70
Cooling Type: Liquid-cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Direct injection
Cylinders: 4
Displacement (ci): 278.3
Bore (in): 4.331
Stroke (in): 4.7241
Rated RPM: 2100
Power Output (hp): 77

Transmission

Type: Gear
Forward Gears: 7
Reverse Gears: 2
Total Gears: -

Dimensions

Length (in): 140
Width (in): -
Height (in): 68.8 (steering wheel)
Operating Weight (lb): 6700

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x2 2WD
Drive Type: 2WD
Steering Type: Power
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Ag
Manufacture - End Year: -
Hitch Type: Three-point hitch (implied by Rear Type: I/II)
Hitch Category: I/II
Hitch Position: Rear
Hitch Capacity (lb): -
Operator Station Type: -
Starter Type: Electric (implied by "Starter volts: 12")
Brake Type: -
Hydraulic System Type: -
