New Holland TS110

Last Updated: September 2024

Overview

The New Holland TS110 is a versatile utility tractor made from 1999 to 2003. It has a strong 4-cylinder diesel engine that produces 98.4 horsepower. This engine is turbocharged and liquid-cooled, making it powerful and efficient. The tractor has a 4-wheel drive system, which helps it work well in tough conditions.

One of the TS110's best features is its transmission. It has 24 forward and 24 reverse gears, giving the driver lots of options for different tasks. The tractor also has a three-point hitch at the back that can lift up to 6,520 pounds, which is very high for its class. The power take-off (PTO) system can run at both 540 and 1000 rpm, making it suitable for various farm equipment. With its hydrostatic power steering and wet disc brakes, the TS110 is easy and safe to operate. Farmers can choose between a basic open cabin with roll-over protection or a comfortable enclosed cab with air conditioning.
Show more...

Key Specifications

Category: Utility

Power Output: 98 hp (73.4 kW)

Transmission: Selective gear fixed ratio

Drive Type: 4x4 MFWD 4WD

Operating Weight: 9795 lb (4443 kg)

Fuel Type: Diesel

New Holland TS110 vs. Similar Tractors

Power Output

The Power Output for the New Holland TS110 is Above Average. It is greater than 82% of similar Utility tractors in our database.

Horsepower distribution of Utility tractors

(across 4.7K+ tractors in our database)

Operating Weight

The Operating Weight for the New Holland TS110 is Above Average. It is greater than 86% of similar Utility tractors in our database.

Operating weight distribution of Utility tractors

(across 4.4K+ tractors in our database)

Engine Displacement

The Engine Displacement for the New Holland TS110 is Above Average. It is greater than 85% of similar Utility tractors in our database.

Engine displacement distribution of Utility tractors

(across 1K+ tractors in our database)

Engine Rated RPM

The Engine Rated RPM for the New Holland TS110 is Below Average. It is greater than 12% of similar Utility tractors in our database.

Engine rated RPM distribution of Utility tractors

(across 1K+ tractors in our database)

Technical Specifications

Engine

Manufacturer
New Holland
Model
Genesis
Cooling Type
Liquid-cooled with oil cooler using engine coolant heat exchanger and radiator for hydraulic and transmission oil
Cylinder Orientation
Inline
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement
304 ci (5.0 L)
Bore
4.40 in (111.8 mm)
Stroke
5.00 in (127.0 mm)
Rated RPM
2070
Power Output
98 hp (73.4 kW)

Transmission

Type
Selective gear fixed ratio
Forward Gears
24
Reverse Gears
24

Drivetrain

Drive Type
4x4 MFWD 4WD
Steering Type
Hydrostatic power
Brake Type
Hydraulic wet disc
