New Holland TG245

Last Updated: September 2024

Overview

The New Holland TG245 is a powerful row crop tractor built from 2006 to 2007. It has a strong engine made by CNH, with 6 cylinders and 248 horsepower. This tractor is designed for tough farm work and can handle big jobs easily.

The TG245 has a 4x4 MFWD (mechanical front-wheel drive) system, which gives it great traction in the field. It has a full power shift transmission with 19 forward gears and 4 reverse gears, letting the driver choose the right speed for any task. The tractor weighs 21,270 pounds, making it sturdy and stable. It has a Category 3 hitch at the back for attaching large implements. With its high engine power and weight, this tractor stands out as above average in its class.
Show more...

Key Specifications

Category: Row Crop

Power Output: 248 hp (184.9 kW)

Transmission: Full power shift

Drive Type: MFWD

Operating Weight: 21270 lb (9648 kg)

Fuel Type: Diesel

Image Gallery

New Holland TG245 Tractor New Holland TG245 Tractor New Holland TG245 Tractor New Holland TG245 Tractor New Holland TG245 Tractor New Holland TG245 Tractor New Holland TG245 Tractor New Holland TG245 Tractor New Holland TG245 Tractor New Holland TG245 Tractor New Holland TG245 Tractor New Holland TG245 Tractor

New Holland TG245 vs. Similar Tractors

Power Output

The Power Output for the New Holland TG245 is Above Average. It is greater than 87% of similar Row Crop tractors in our database.

Horsepower distribution of Row Crop tractors

(across 1.1K+ tractors in our database)

Operating Weight

The Operating Weight for the New Holland TG245 is Above Average. It is greater than 87% of similar Row Crop tractors in our database.

Operating weight distribution of Row Crop tractors

(across 1.3K+ tractors in our database)

Engine Displacement

The Engine Displacement for the New Holland TG245 is Above Average. It is greater than 88% of similar Row Crop tractors in our database.

Engine displacement distribution of Row Crop tractors

(across 1K+ tractors in our database)

Engine Rated RPM

The Engine Rated RPM for the New Holland TG245 is Average. It is greater than 58% of similar Row Crop tractors in our database.

Engine rated RPM distribution of Row Crop tractors

(across 1K+ tractors in our database)

Technical Specifications

Engine

Manufacturer
CNH
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Induction Type
Intercooled turbocharged
Cylinders
6
Displacement
505 ci (8.3 L)
Bore
4.49 in (114.0 mm)
Stroke
5.32 in (135.0 mm)
Rated RPM
2200
Power Output
248 hp (184.9 kW)

Transmission

Type
Full power shift
Forward Gears
19
Reverse Gears
4
Total Gears
23

Drivetrain

Chassis
4x4 MFWD 4WD
Drive Type
MFWD
Steering Type
Hydrostatic power
