New Holland TG245

Last Updated: June 2024

Overview

The New Holland TG245 is a robust row-crop tractor designed with the modern farmer in mind. Equipped with a full-power shift transmission featuring 19 forward and 4 reverse gears, it provides great versatility and ease of operation across a wide range of tasks. The tractor is outfitted with a durable CNH 6-cylinder, liquid-cooled, turbocharged diesel engine, which delivers a solid 248 horsepower, ensuring sufficient power for demanding fieldwork. The TG245's chassis is a 4x4 MFWD 4WD, offering improved traction and handling capabilities on various terrains. Engineered with a hydrostatic power steering system, it ensures precise control and maneuverability. With a robust wheelbase of 121.2 inches and an operating weight of 21,270 pounds, this tractor is designed for heavy-duty work and can accommodate various attachments for different farming needs. It was manufactured between 2006 and 2007, providing a brief but prominent presence in the farm equipment market.
Show more...

Key Specifications

Category: Row Crop

Power Output: 248

Transmission: Full power shift

Drive Type: MFWD (Mechanical Front Wheel Drive)

Operating Weight: 21270

Fuel Type: Diesel

New Holland TG245 vs. Similar Tractors

Power Output
Above Average
Greater than 82% of similar tractors.
Operating Weight
Above Average
Greater than 73% of similar tractors.

Technical Specifications

Engine

Manufacturer
CNH
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Intercooled turbocharged
Cylinders
6
Displacement (ci)
505
Bore (in)
4.488
Stroke (in)
5.315
Rated RPM
2200
Power Output (hp)
248

Transmission

Type
Full power shift
Forward Gears
19
Reverse Gears
4
Total Gears
23

Dimensions

Length (in)
-
Width (in)
-
Height (in)
-
Operating Weight (lb)
21270

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
MFWD (Mechanical Front Wheel Drive)
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
2007
Hitch Type
Category 3 (Rear Type: III)
Hitch Category
3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
