New Holland TD5020

Last Updated: September 2024

Overview

The New Holland TD5020 is a utility tractor built from 2009 to 2019. It's a 2WD model with hydrostatic power steering, making it easy to control. The tractor has a 20-forward and 12-reverse gear transmission, giving farmers lots of options for different tasks.

Under the hood, the TD5020 has a 4-cylinder diesel engine made by FPT. The engine is turbocharged and intercooled, which helps it produce 72 horsepower. This power output is above average compared to other tractors. The engine size is average at 195 cubic inches. One standout feature is the tractor's very high hitch capacity of 11,900 pounds, which is great for heavy lifting jobs. Farmers can choose between a ROPS or cab version, depending on their needs. The TD5020 also meets Tier III emissions standards, showing it's designed with environmental concerns in mind.
Show more...

Key Specifications

Category: Utility

Power Output: 72 hp (53.7 kW)

Transmission: Partially synchronized mechanical shuttle / Creeper

Drive Type: 2WD

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
FPT
Model
F5C
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Induction Type
Turbocharged intercooled
Cylinders
4
Displacement
195 ci (3.2 L)
Bore
3.90 in (99.0 mm)
Stroke
4.09 in (104.0 mm)
Rated RPM
2500
Power Output
72 hp (53.7 kW)

Transmission

Type
Partially synchronized mechanical shuttle / Creeper
Forward Gears
20
Reverse Gears
12

Drivetrain

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Hydrostatic power
