New Holland TC34DA

Last Updated: June 2024

Overview

The New Holland TC34DA is a compact utility tractor that was manufactured by New Holland under the Boomer TC-A Series from 2005 to 2008. It features a Shibaura N843L diesel engine with a power output of 35 hp at an engine rated RPM of 2600. The tractor provides a hydrostatic transmission with infinite (3-range) gear options for both forward and reverse movement, and is designed with a 4x4 MFWD 4WD chassis for enhanced traction and maneuverability. The power steering facilitates ease of operation, especially during long working hours. With a wheelbase of 63 inches and an operating weight of 2514 lbs, the TC34DA ensures stability in a variety of tasks. The tractor comes standard with a ROPS (Roll-Over Protection Structure) with an overall height of 87.8 inches, providing safety for the operator. It also features a hydraulic system with an open center design and a category 3 hitch, although specific details about the hitch lift capacity or PTO speeds were not provided.
Show more...

Key Specifications

Category: Utility

Power Output: 35

Transmission: Hydrostatic

Drive Type: 4WD

Operating Weight: 2514

Fuel Type: Diesel

New Holland TC34DA vs. Similar Tractors

Power Output
Average
Greater than 32% of similar tractors.
Operating Weight
Below Average
Greater than 20% of similar tractors.

Technical Specifications

Engine

Manufacturer
Shibaura
Model
N843L
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
3
Displacement (ci)
101.4
Bore (in)
3.31
Stroke (in)
3.94
Rated RPM
2600
Power Output (hp)
35

Transmission

Type
Hydrostatic
Forward Gears
Infinite (3-range)
Reverse Gears
Infinite (3-range)
Total Gears
-

Dimensions

Length (in)
106.2
Width (in)
54.3
Height (in)
87.8
Operating Weight (lb)
2514

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
2008
Hitch Type
-
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
ROPS
Starter Type
Electric - 12 volts
Brake Type
-
Hydraulic System Type
Open Center
