New Holland TC24D

Last Updated: June 2024

Overview

The New Holland TC24D is a compact utility tractor that was part of the Boomer TC Series. It was manufactured between 1999 and 2003 and features a Shibaura liquid-cooled diesel engine with a power output of 24 horsepower and a rated RPM of 2600. The tractor is known for its versatility, supporting various tire configurations including agricultural, lawn/turf, and industrial. It offers a gear-driven and hydrostatic transmission with 9 forward and 3 reverse gears, making it a fit for different types of tasks. The tractor's steering is power assisted, enhancing maneuverability, particularly with a turning radius of 8.1 feet. With an operating weight of 1723 pounds, a three-point hitch rated for 1265 lbs lift capacity, and both MFWD and 4WD options, it is a robust machine capable of tackling a variety of farm or landscaping jobs. The TC24D also comes with the convenience of a ROPS operator station and is known for its compact dimensions, sporting a length of 106.3 inches, a width of 44.7 inches, and a height of 81.2 inches, making it suitable for operations in confined spaces.
Show more...

Key Specifications

Category: Utility

Power Output: 24

Transmission: Hydrostatic and Gear

Drive Type: MFWD 4WD

Operating Weight: 1723

Fuel Type: Diesel

New Holland TC24D vs. Similar Tractors

Power Output
Below Average
Greater than 16% of similar tractors.
Hitch Capacity
Excellent
Greater than 93% of similar tractors.
Operating Weight
Below Average
Greater than 13% of similar tractors.

Technical Specifications

Engine

Manufacturer
Shibaura
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
3
Displacement (ci)
69
Bore (in)
-
Stroke (in)
-
Rated RPM
2600
Power Output (hp)
24

Transmission

Type
Hydrostatic and Gear
Forward Gears
9
Reverse Gears
3
Total Gears
-

Dimensions

Length (in)
106.3
Width (in)
44.7
Height (in)
81.2
Operating Weight (lb)
1723

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
MFWD 4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag, Lawn/Turf, Industrial
Manufacture - End Year
2003
Hitch Type
Three-Point Hitch
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
1265 lbs @ 24 inches
Operator Station Type
ROPS
Starter Type
Electric Starter
Brake Type
-
Hydraulic System Type
-
