New Holland T2330

Last Updated: July 2024

Overview

The New Holland T2330 is a utility tractor powered by a 4-cylinder liquid-cooled ISM Diesel engine with a displacement of 135 cubic inches (2216 ml). The engine is rated at 43.62 hp at 2802 rpm and produces a maximum torque of 95 lb-ft at 1799 rpm with 16.1% torque rise. It has a 12-speed synchro shuttle transmission with a single dry disc clutch operated by foot pedal. Key specifications include a hydraulic pump delivery rate of 9.4 GPM at minimum pressure, drawbar pull of 2350 lbs, PTO power of 41.54 HP at 540 rpm, and operating weight of 3430 lbs. Dimensions are 125.2" length, 66.6" width, 95" height with ROPS. Rear tires are 17.5L-24 with 8-12 psi, and front tires are 10-16.5 with 6-20 psi. Brakes are single wet disc operated by two foot pedals. Sound levels are 92.6 dB(A) at no load in 7th gear and 83.5 dB(A) for bystander in 12th gear. The hydraulic system has an open relief valve pressure of 2502 psi.
Show more...

Key Specifications

Category: Utility

Power Output: 43.62

Transmission: 12-speed synchro shuttle

Drive Type: 4WD

Operating Weight: 3430

Fuel Type: No. 2 Diesel

Image Gallery

New Holland T2330 Tractor New Holland T2330 Tractor New Holland T2330 Tractor New Holland T2330 Tractor New Holland T2330 Tractor New Holland T2330 Tractor New Holland T2330 Tractor New Holland T2330 Tractor New Holland T2330 Tractor New Holland T2330 Tractor

New Holland T2330 vs. Similar Tractors

Power Output
Average
Greater than 49% of similar tractors.
Operating Weight
Average
Greater than 30% of similar tractors.

Technical Specifications

Engine

Manufacturer
ISM Diesel
Model
-
Cooling Type
liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
No. 2 Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
135
Bore (in)
3.307
Stroke (in)
3.937
Rated RPM
2802
Power Output (hp)
43.62

Transmission

Type
12-speed synchro shuttle
Forward Gears
12
Reverse Gears
12
Total Gears
-

Dimensions

Length (in)
125.2
Width (in)
66.6
Height (in)
95 (ROPS)
Operating Weight (lb)
3430

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 1
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
open center

Test Results

Nebraska Tractor Test Laboratory - Test Date: December 2-3, 2008

Maximum Power and Fuel Consumption

  • Rated Engine Speed: 43.62 HP (32.53 kW) at 2802 rpm
  • Fuel Consumption at Rated Speed: 3.29 Gal/hr (12.46 l/h) with a fuel efficiency of 0.526 lb/hp.hr (0.320 kg/kW.h)
  • Maximum Power: 44.64 HP (33.29 kW) at 2752 rpm
  • Fuel Consumption at Maximum Power: 3.88 Gal/hr (14.68 l/h) with a fuel efficiency of 0.606 lb/hp.hr (0.369 kg/kW.h)

Drawbar Performance

  • Hydraulic Pump Delivery Rate: 9.4 GPM (35.4 l/min) at minimum pressure and rated engine speed
  • Drawbar Pull: 2350 lbs (10.5 kN)

Torque and Engine Performance

  • Maximum Torque: 95 lb.-ft. (129 Nm) at 1799 rpm
  • Torque Rise: 16.1%

Hydraulic Performance

  • Maximum Force Exerted: 2350 lbs (10.5 kN)
  • Pump Delivery Rate: 9.4 GPM (35.4 l/min) at minimum pressure and rated engine speed
  • Hydraulic Power: 10.7 HP (8.0 kW) at delivery pressure of 2055 psi (142 bar)

Tractor Sound Level Without Cab

  • At No Load in 7th Gear: 92.6 dB(A)
  • Bystander in 12th Gear: 83.5 dB(A)



Nebraska Tractor Test Lab.(2008).Test 1938: New Holland T2330, New Holland TC50, New Holland Boomer 3050. Lincoln, NE:Nebraska Tractor Test Laboratory. Retrieved from https://digitalcommons.unl.edu/tractormuseumlit/2322
