New Holland Boomer TZ22DA

Last Updated: June 2024

Overview

The New Holland Boomer TZ22DA is powered by a Shibaura S753 diesel engine, which is a three-cylinder, liquid-cooled design with a displacement of 58.2 cubic inches. It features a bore and stroke of 2.953x2.835 inches and an engine power output of 22 horsepower at a rated RPM of 3000. The tractor comes equipped with a hydrostatic transmission offering infinite gearing options for both forward and reverse motion within a 2-range setup. This provides easy and precise control over the vehicle's speed, making it well-suited to a variety of tasks. The tractor's purpose and utility are enhanced by an open operator station and a Category 1 rear hitch. Additional features include glow plugs for pre-heating to assist with cold starts. Its operating weight stands at 1320 pounds, which gives it a sturdy presence for its size. The New Holland Boomer TZ22DA is designed to cater to a variety of utility needs in the small scale agricultural or land maintenance sectors.
Show more...

Key Specifications

Power Output: 22

Transmission: Hydrostatic

Operating Weight: 1320

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
Shibaura
Model
S753
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Natural (assuming from lack of turbo or supercharger mention)
Cylinders
3
Displacement (ci)
58.2
Bore (in)
2.953
Stroke (in)
2.835
Rated RPM
3000
Power Output (hp)
22

Transmission

Type
Hydrostatic
Forward Gears
Infinite (2-range)
Reverse Gears
Infinite (2-range)
Total Gears
-

Dimensions

Length (in)
-
Width (in)
-
Height (in)
-
Operating Weight (lb)
1320

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
Power (assuming from Steering flow: 1.85 gpm, as hydraulic flow is typically related to power steering)
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 1 (assuming from Rear Type: I)
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
Open
Starter Type
Electric (assuming from Engine - Starter volts: 12)
Brake Type
-
Hydraulic System Type
Open Center
