New Holland 1620

Last Updated: September 2024

Overview

The New Holland 1620 is a utility tractor that was made from 1992 to 1997. It's a small, lightweight tractor with a 2WD drive system and power steering. This tractor is good for basic farm tasks and yard work.

The 1620 has a Shibaura diesel engine with 3 cylinders. It's liquid-cooled and naturally aspirated, which means it doesn't use a turbocharger. The engine is below average in size at 81.2 ci, but it runs at a very high 2600 rpm. It produces 27.3 hp, which is below average for tractors. The tractor uses a hydrostatic transmission, giving it smooth, easy-to-control speed changes in both forward and reverse. It has agricultural tires and a Category I hitch for attaching implements.

This New Holland model is compact, measuring 112.4 inches long, 48.4 inches wide, and 84.3 inches tall. It's quite light at 2233 lb, making it easy to move around. The tractor has a ROPS (Roll-Over Protective Structure) for safety and uses an open center hydraulic system. With its electric starter and 63-inch wheelbase, the 1620 is a handy, user-friendly tractor for smaller jobs.
Show more...

Key Specifications

Category: Utility

Power Output: 27 hp (20.4 kW)

Transmission: Hydrostatic

Drive Type: 2WD

Operating Weight: 2233 lb (1013 kg)

Fuel Type: Diesel

New Holland 1620 vs. Similar Tractors

Power Output

The Power Output for the New Holland 1620 is Below Average. It is greater than 21% of similar Utility tractors in our database.

Horsepower distribution of Utility tractors

(across 4.1K+ tractors in our database)

Operating Weight

The Operating Weight for the New Holland 1620 is Below Average. It is greater than 15% of similar Utility tractors in our database.

Operating weight distribution of Utility tractors

(across 3.9K+ tractors in our database)

Engine Displacement

The Engine Displacement for the New Holland 1620 is Below Average. It is greater than 15% of similar Utility tractors in our database.

Engine displacement distribution of Utility tractors

(across 1K+ tractors in our database)

Engine Rated RPM

The Engine Rated RPM for the New Holland 1620 is Above Average. It is greater than 77% of similar Utility tractors in our database.

Engine rated RPM distribution of Utility tractors

(across 1K+ tractors in our database)

Technical Specifications

Engine

Manufacturer
Shibaura
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
3
Displacement
81 ci (1.3 L)
Bore
3.31 in (84.0 mm)
Stroke
3.15 in (80.0 mm)
Rated RPM
2600
Power Output
27 hp (20.4 kW)

Transmission

Type
Hydrostatic
Forward Gears
Infinite
Reverse Gears
Infinite

Drivetrain

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Power
