New Holland 1530

Last Updated: June 2024

Overview

The New Holland 1530 is a versatile 2WD/4WD compact utility tractor that offers reliable performance with its Shibaura three-cylinder diesel engine. Available with either sliding gear or hydrostatic transmissions, it provides an adaptable operation to meet various task demands. The steering comes with the standard hydrostatic power option or the optional SuperSteer feature, ensuring precise control in different conditions. The tractor also emphasizes operator comfort with two types of ROPS and demonstrates strong lifting capabilities with its Category I hitch. Despite its compact design, the New Holland 1530 maintains productivity with PTO options and a robust hydraulic system.

Key Specifications

Category: Utility

Power Output: 25

Transmission: Sliding gear or hydrostatic (exact option Unknown)

Drive Type: 2WD or 4WD (exact option Unknown)

Operating Weight: 2315 (2WD) / 2480 (4WD)

Fuel Type: Diesel

Image Gallery

New Holland 1530 Tractor

New Holland 1530 vs. Similar Tractors

Power Output

Below Average

Greater than 18% of similar tractors.

Hitch Capacity

Average

Greater than 33% of similar tractors.

Operating Weight

Excellent

Greater than 95% of similar tractors.

Technical Specifications

Engine

Manufacturer: Shibaura
Model: Shibaura
Cooling Type: Liquid-cooled
Cylinder Orientation: Inline
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Natural aspirated
Cylinders: 3
Displacement (ci): 81.2
Bore (in): -
Stroke (in): -
Rated RPM: 2600
Power Output (hp): 25

Transmission

Type: Sliding gear or hydrostatic (exact option Unknown)
Forward Gears: 9 (Assuming sliding gear type) or Infinite (Assuming hydrostatic type)
Reverse Gears: 3 (Assuming sliding gear type) or Infinite (Assuming hydrostatic type)
Total Gears: Unknown (Different transmission options provide a different number of gears)

Dimensions

Length (in): 106.3 (2WD) / 105.9 (4WD)
Width (in): 53.9
Height (in): 87.8
Operating Weight (lb): 2315 (2WD) / 2480 (4WD)

Power Take-Off (PTO)

PTO Type: Live (hydro) or Continuous live (exact option Unknown)
PTO Speed 1 (rpm): 540
PTO Speed 2 (rpm): 2000
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x2 2WD
Drive Type: 2WD or 4WD (exact option Unknown)
Steering Type: Hydrostatic power or SuperSteer (optional)
Coolant Capacity (qts): -
Front Tire Diameter (in): 16 (Assuming for 5.50x16 size)
Front Tire Width (in): 5.5 (Assuming for 5.50x16 size)
Rear Tire Diameter (in): 24 (Assuming for 11.2x24 size)
Rear Tire Width (in): 11.2 (Assuming for 11.2x24 size)
Front/Rear Rim Diameter (in): -
Tire Type: Ag, Lawn/Turf, Industrial (exact option Unknown)
Manufacture - End Year: 1999
Hitch Type: -
Hitch Category: I
Hitch Position: Rear
Hitch Capacity (lb): 1920 lbs
Operator Station Type: Two-post fixed ROPS or foldable ROPS (optional)
Starter Type: Electric
Brake Type: Wet disc
Hydraulic System Type: Open center
