Montana 2740

Last Updated: June 2024

Overview

The Montana 2740 is a compact utility tractor equipped with a robust four-wheel-drive (4x4 MFWD 4WD) system, designed to handle a variety of tasks in different agricultural settings. Its power is derived from a 27 hp Daedong 3-cylinder diesel engine, with a displacement of 85.43 cubic inches, featuring indirect injection and liquid cooling to maintain optimal performance. The tractor achieves a rated RPM of 2600. For ease of operation, it utilizes a power steering system and an 8-speed sync shuttle transmission, which provides equal numbers of forward and reverse gears for various tasks. The tractor's operating weight stands at 2600 pounds and it offers notable ground clearance of 11.6 inches, allowing for effective maneuvering in varied terrain. Dimensions are specified with a length of 115.4 inches and a height of 93.2 inches. Tire specifications are agricultural tires with front tires measuring 6.0-14.0 inches and rear tires at 9.5-24.0 inches, providing adequate traction for typical farm work. Detailed specifications for additional features such as the starter type indicate a 12-volt system but information on the hydraulic system, PTO, and operator station remains unspecified.
Show more...

Key Specifications

Category: Utility

Power Output: 27

Transmission: Sync shuttle

Drive Type: 4WD

Operating Weight: 2600

Fuel Type: Diesel

Montana 2740 vs. Similar Tractors

Power Output
Below Average
Greater than 21% of similar tractors.
Operating Weight
Below Average
Greater than 21% of similar tractors.

Technical Specifications

Engine

Manufacturer
Daedong
Model
3A139LG
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Indirect injection
Cylinders
3
Displacement (ci)
85.43
Bore (in)
3.15
Stroke (in)
3.64
Rated RPM
2600
Power Output (hp)
27

Transmission

Type
Sync shuttle
Forward Gears
8
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
115.4
Width (in)
-
Height (in)
93.2
Operating Weight (lb)
2600

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
14
Front Tire Width (in)
6
Rear Tire Diameter (in)
24
Rear Tire Width (in)
9.5
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
I
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
12 volts
Brake Type
-
Hydraulic System Type
-
