Mitsubishi MT368

Last Updated: June 2024

Overview

The Mitsubishi MT368 is a compact utility tractor that offers a combination of power and versatility for a range of agricultural tasks. Featuring a Mitsubishi S4L2 four-cylinder liquid-cooled diesel engine, it provides 36 horsepower and a displacement of 107.3 cubic inches. With a 16-speed transmission system, operators can handle various tasks with ease, whether they require slow and controlled movement or more speed. The tractor comes equipped with a Mechanical Front Wheel Drive (MFWD) chassis, which, along with the power steering, enhances maneuverability across different terrains. Consistent with 'utility' in its category, the MT368 possesses a sturdy build with a wheelbase of 72.2 inches, a length of 134.1 inches, a width of 57.9 inches, and a height of 92.9 inches. The tractor also boasts a notable operating weight of 3616 lbs and has standard agricultural tires with front size 8-18 and rear size 12.4-28, ensuring it can perform optimally in various ground conditions. The MT368's functionality is also evident in its implements, though specific data on the hydraulic system, PTO, and hitch capabilities are not provided. This model is designed to deliver reliable performance and cater to the diverse needs of modern compact farming operations.
Show more...

Key Specifications

Category: Utility

Power Output: 36

Drive Type: MFWD (Mechanical Front Wheel Drive)

Operating Weight: 3616

Fuel Type: Diesel

Mitsubishi MT368 vs. Similar Tractors

Power Output
Average
Greater than 32% of similar tractors.
Operating Weight
Average
Greater than 31% of similar tractors.

Technical Specifications

Engine

Manufacturer
Mitsubishi
Model
S4L2
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
4
Displacement (ci)
107.3
Bore (in)
3.07
Stroke (in)
3.62
Rated RPM
2700
Power Output (hp)
36

Transmission

Type
-
Forward Gears
16
Reverse Gears
16
Total Gears
32

Dimensions

Length (in)
134.1
Width (in)
57.9
Height (in)
92.9
Operating Weight (lb)
3616

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
MFWD (Mechanical Front Wheel Drive)
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
28
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
I
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
