Mitsubishi MT3500

Last Updated: June 2024

Overview

The Mitsubishi MT3500 is a compact utility tractor that is equipped with a Mitsubishi 1.5L 3-cylinder liquid-cooled turbocharged diesel engine, capable of delivering 35 horsepower at 2500 rpm. With a four-wheel drive chassis and power steering, this tractor is designed to handle a variety of tasks around the farm. The gear transmission offers 9 forward and 3 reverse gears for versatility in operation. The standard agricultural tires can be switched out for optional lawn or turf tires, depending on usage needs. The MT3500 is fitted with a roll-over protection structure (ROPS) for safety, stands 98.6 inches tall with ROPS, is 119.3 inches long and 54.3 inches wide, with a ground clearance of 12.8 inches, ensuring sufficient maneuverability for a multitude of tasks. The rear hitch is a Category I type, though the lift capacity is unknown. This model also features a hydraulic flow of 3.4 gallons per minute for potential hydraulic implement usage.
Show more...

Key Specifications

Category: Utility

Power Output: 35

Transmission: Gear

Drive Type: 4WD

Operating Weight: 2767

Fuel Type: Turbocharged Diesel

Mitsubishi MT3500 vs. Similar Tractors

Power Output
Average
Greater than 32% of similar tractors.
Operating Weight
Below Average
Greater than 23% of similar tractors.

Technical Specifications

Engine

Manufacturer
Mitsubishi
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Turbocharged Diesel
Induction Type
Turbocharged
Cylinders
3
Displacement (ci)
91.3
Bore (in)
3.307
Stroke (in)
3.543
Rated RPM
2500
Power Output (hp)
35

Transmission

Type
Gear
Forward Gears
9
Reverse Gears
3
Total Gears
-

Dimensions

Length (in)
119.3
Width (in)
54.3
Height (in)
98.6 with ROPS
Operating Weight (lb)
2767

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
24
Rear Tire Width (in)
11.2
Front/Rear Rim Diameter (in)
-
Tire Type
Standard: Agricultural, Optional: Lawn/Turf
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
-
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
ROPS (Roll-Over Protection Structure)
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
