Mitsubishi GX46

Last Updated: June 2024

Overview

The Mitsubishi GX46 is a compact utility tractor that is known for its reliability and versatility. Equipped with a Mitsubishi K4N engine, this model boasts a power output of 46 horsepower and a displacement of 139.7 cubic inches. It has a four-wheel-drive (4WD) chassis that offers improved traction and performance in various agricultural tasks. The tractor has a power steering system for ease of maneuverability and is capable of 2600 RPMs at rated power. The 16-speed transmission provides ample options for adjusting speed to match the working conditions. This tractor stands out with its full-frame construction, a dry disc clutch for transmission operation, and a diesel-fueled, liquid-cooled four-cylinder engine. It has a substantial operating weight of 4045 pounds, emphasizing its durability and the ability to handle heavy-duty tasks. Additionally, the GX46 maintains a relatively large footprint, with a length of over 134 inches and a width of 61.2 inches, ensuring stability during operation.
Show more...

Key Specifications

Category: Utility

Power Output: 46

Drive Type: 4WD

Operating Weight: 4045

Fuel Type: Diesel

Mitsubishi GX46 vs. Similar Tractors

Power Output
Average
Greater than 44% of similar tractors.
Operating Weight
Average
Greater than 37% of similar tractors.

Technical Specifications

Engine

Manufacturer
Mitsubishi
Model
K4N
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
139.7
Bore (in)
3.54
Stroke (in)
3.54
Rated RPM
2600
Power Output (hp)
46

Transmission

Type
-
Forward Gears
16
Reverse Gears
16
Total Gears
32

Dimensions

Length (in)
134.25
Width (in)
61.2
Height (in)
94.5
Operating Weight (lb)
4045

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard (ag)
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
