Mitsubishi GX401

Last Updated: June 2024

Overview

The Mitsubishi GX401 is a robust compact utility tractor designed for a variety of tasks. With its 40 horsepower Mitsubishi diesel engine and 135.2 cubic inches of displacement, it is capable of handling various agricultural and utility applications. The tractor operates on a 4WD chassis, giving it enhanced traction and performance in different terrains. Steering is power-assisted, providing easier handling and maneuverability. This tractor features an e-Shift transmission system and a total of 24 gears, although the specific number of forward and reverse gears isn't detailed in the provided data. It has a wheelbase of 74.6 inches, ensuring stability, and power is delivered efficiently through standard ag tires, with adjustable rear tread allowing for variable row widths. The GX401 combines a robust powerplant with advanced features such as high ground clearance, which improves its functionality across diverse operations. It is well-equipped for tasks that require strength and adaptability, making it a reliable workhorse for its operators.
Show more...

Key Specifications

Category: Utility

Power Output: 40

Transmission: e-Shift

Drive Type: 4WD

Operating Weight: 3726

Fuel Type: Diesel

Mitsubishi GX401 vs. Similar Tractors

Power Output
Average
Greater than 37% of similar tractors.
Operating Weight
Average
Greater than 33% of similar tractors.

Technical Specifications

Engine

Manufacturer
Mitsubishi
Model
S4L3-12A
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
135.2
Bore (in)
-
Stroke (in)
-
Rated RPM
2600
Power Output (hp)
40

Transmission

Type
e-Shift
Forward Gears
-
Reverse Gears
-
Total Gears
24

Dimensions

Length (in)
134.1
Width (in)
61.2
Height (in)
93.5
Operating Weight (lb)
3726

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
26
Rear Tire Width (in)
13.6
Front/Rear Rim Diameter (in)
-
Tire Type
Standard (ag)
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
