Mitsubishi GX40

Last Updated: June 2024

Overview

The Mitsubishi GX40 is a versatile Compact Utility tractor adept for a variety of tasks. It is equipped with a robust four-wheel drive system (4x4 MFWD 4WD) which provides excellent traction and stability across different terrains. The tractor is powered by a reliable Mitsubishi K4N diesel engine with a displacement of 139.7 cubic inches, providing a power output of 40 horsepower at a rated RPM of 2600. Its liquid-cooled engine ensures optimal thermal regulation during prolonged work periods. The GX40 boasts a power steering feature for ease of maneuverability and a 16-speed transmission that offers ample choice in operating speed and control needed for a variety of tasks. With an electric starter and a 12-volt system, the tractor ensures dependable ignition. Its substantial weight of 3979 pounds combined with a wheelbase of 74.8 inches and ground clearance of 14 inches allows for good stability and utility across numerous applications. The tractor's dimensions are conducive to work in limited-space conditions while maintaining the ability to tackle demanding jobs.
Show more...

Key Specifications

Category: Utility

Power Output: 40

Drive Type: 4WD

Operating Weight: 3979

Fuel Type: Diesel

Mitsubishi GX40 vs. Similar Tractors

Power Output
Average
Greater than 37% of similar tractors.
Operating Weight
Average
Greater than 36% of similar tractors.

Technical Specifications

Engine

Manufacturer
Mitsubishi
Model
K4N
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
139.7
Bore (in)
3.54
Stroke (in)
3.54
Rated RPM
2600
Power Output (hp)
40

Transmission

Type
-
Forward Gears
16
Reverse Gears
16
Total Gears
-

Dimensions

Length (in)
134.25
Width (in)
61.2
Height (in)
93.5
Operating Weight (lb)
3979

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard (ag)
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
