Mitsubishi GSK236

Last Updated: June 2024

Overview

The Mitsubishi GSK236 is a half-track crawler tractor notable for its robust track system designed to provide enhanced traction on a variety of terrains. It comes equipped with a power steering system to facilitate easier maneuverability despite its heavy-duty tracks. The GSK236 is propelled by a 23.2 horsepower Isuzu E3CD diesel engine, with a liquid-cooled, 3-cylinder motor that maximizes efficiency and durability. The tractor has a significant operating weight of 3,053 pounds and possesses a 12-speed manual transmission ideal for a wide array of agricultural tasks with working speeds optimized for various needs. The tractor's stance is complemented by its 59.1-inch wheelbase and a ground clearance of 14.6 inches, which supports better navigation over obstacles. Its dimensions, with a length of 114.2 inches, a width of 55.1 inches, and a heightened ROPS at 78.5 inches, affirm its solid and secure construction with emphasized safety. The GSK236's capability in agriculture is solidified with 370mm track width at the rear and an undefined agricultural tire configuration at the front.
Show more...

Key Specifications

Category: Crawler

Power Output: 23.2

Transmission: Manual

Drive Type: Track

Operating Weight: 3053

Fuel Type: Diesel

Mitsubishi GSK236 vs. Similar Tractors

Power Output
Poor
Greater than 9% of similar tractors.
Operating Weight
Below Average
Greater than 23% of similar tractors.

Technical Specifications

Engine

Manufacturer
Isuzu
Model
E3CD
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
3
Displacement (ci)
91.4
Bore (in)
3.39
Stroke (in)
3.39
Rated RPM
2500
Power Output (hp)
23.2

Transmission

Type
Manual
Forward Gears
12
Reverse Gears
-
Total Gears
24

Dimensions

Length (in)
114.2
Width (in)
55.1
Height (in)
78.5 (ROPS)
Operating Weight (lb)
3053

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
Half-track
Drive Type
Track
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
370mm Tracks (Unknown in inches)
Front/Rear Rim Diameter (in)
-
Tire Type
Tracks (Rear), Agricultural front (Specified as Ag front, details not provided)
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
ROPS (Roll-Over Protection Structure)
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
