Mitsubishi GSK226

Last Updated: June 2024

Overview

The Mitsubishi GSK226 is a half-track crawler tractor, recognized by its combined use of front tires and rear tracks optimized for various types of terrain and demanding field conditions. This tractor model features a 21.6 horsepower engine, lending sufficient power for a range of agricultural tasks. It sports a 12-speed manual transmission, ensuring versatility and control for operation over different speeds and conditions. The track configuration provides increased stability and traction, which improves performance on uneven ground. At its heart lies the robust Iseki E3112 diesel-powered, three-cylinder engine, which is liquid-cooled and sustains a 2500 RPM rated speed. The GSK226 exhibits a practical wheelbase of 53.4 inches, which supports a total length of 102.4 inches and a height of 77.6 inches when equipped with ROPS. This tractor's ground clearance stands at 13.4 inches, favorable for sidestepping potential obstructions during fieldwork. Given its 2282-pound operating weight, the GSK226 is a mid-weight class tractor suitable for various farming operations requiring durability and maneuverability.
Show more...

Key Specifications

Category: Crawler

Power Output: 21.6

Transmission: Manual

Drive Type: Track

Operating Weight: 2282

Fuel Type: Diesel

Mitsubishi GSK226 vs. Similar Tractors

Power Output
Poor
Greater than 7% of similar tractors.
Operating Weight
Below Average
Greater than 20% of similar tractors.

Technical Specifications

Engine

Manufacturer
Iseki
Model
E3112
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally Aspirated
Cylinders
3
Displacement (ci)
68.5
Bore (in)
3.08
Stroke (in)
3.07
Rated RPM
2500
Power Output (hp)
21.6

Transmission

Type
Manual
Forward Gears
12
Reverse Gears
12
Total Gears
-

Dimensions

Length (in)
102.4
Width (in)
49.6
Height (in)
77.6
Operating Weight (lb)
2282

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
half-track
Drive Type
Track
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag front and tracks rear
Manufacture - End Year
-
Hitch Type
JIS0
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
