Mitsubishi GSK206

Last Updated: September 2024

Overview

The Mitsubishi GSK206 is a compact crawler tractor designed for tough jobs in tight spaces. This half-track machine combines wheels in front with tracks in the back, giving it great traction and stability. It's powered by a small but efficient Iseki E3112 diesel engine with three cylinders. The engine is liquid-cooled and naturally aspirated, meaning it doesn't use a turbocharger.

This tractor is built for versatility, with a manual transmission offering 12 forward and 12 reverse gears. It has power steering for easy control and an electric starter for quick engine starts. The GSK206 is quite small, measuring just over 102 inches long, 49 inches wide, and 77 inches tall. It's also lightweight for a crawler, weighing only 2,282 pounds. Despite its small size, it packs a punch with 19.7 horsepower, which is average for its class. The tractor's compact design and track system make it ideal for working in narrow rows or on slopes where larger tractors might struggle.
Show more...

Key Specifications

Category: Crawler

Power Output: 20 hp (14.7 kW)

Transmission: Manual

Drive Type: Track

Operating Weight: 2282 lb (1035 kg)

Fuel Type: Diesel

Mitsubishi GSK206 vs. Similar Tractors

Power Output

The Power Output for the Mitsubishi GSK206 is Poor. It is greater than 3% of similar Crawler tractors in our database.

Horsepower distribution of Crawler tractors

(across 0.1K+ tractors in our database)

Operating Weight

The Operating Weight for the Mitsubishi GSK206 is Poor. It is greater than 4% of similar Crawler tractors in our database.

Operating weight distribution of Crawler tractors

(across 0.1K+ tractors in our database)

Engine Displacement

The Engine Displacement for the Mitsubishi GSK206 is Poor. It is greater than 2% of similar Crawler tractors in our database.

Engine displacement distribution of Crawler tractors

(across 1K+ tractors in our database)

Engine Rated RPM

The Engine Rated RPM for the Mitsubishi GSK206 is Above Average. It is greater than 82% of similar Crawler tractors in our database.

Engine rated RPM distribution of Crawler tractors

(across 1K+ tractors in our database)

Technical Specifications

Engine

Manufacturer
Iseki
Model
E3112
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
3
Displacement
68 ci (1.1 L)
Bore
3.08 in (78.2 mm)
Stroke
3.07 in (78.0 mm)
Rated RPM
2500
Power Output
20 hp (14.7 kW)

Transmission

Type
Manual
Forward Gears
12
Reverse Gears
12

Drivetrain

Chassis
Half-track
Drive Type
Track
Steering Type
Power
