Mitsubishi GS230

Last Updated: June 2024

Overview

The Mitsubishi GS230 is a compact utility tractor that offers a versatile and powerful solution for a range of agricultural tasks. This model features a reliable Mitsubishi S3L2 three-cylinder diesel engine with a liquid-cooling system and a 22.7 horsepower output, matched with a 12-speed manual transmission for optimum control and efficiency. The tractor's chassis boasts a 4-wheel drive with a power steering system, providing excellent maneuverability and capability across different terrains. With a wheelbase of 57.1 inches and operating weights available for both ROPS and cab configurations, the GS230 is designed to offer robust stability and comfort in operation. It is commonly found with agricultural-standard tires, featuring a front tire size around 6-14 and a rear tire size of 9.5-22, ensuring good traction and field performance. Despite being well-equipped for various tasks, the tractor's exact hydraulic system details, brake type, PTO speeds, and certain specific dimensions remain unspecified, which may require direct consultation from the manufacturer or inspection of the tractor for potential owners seeking these specifics.
Show more...

Key Specifications

Category: Utility

Power Output: 22.7

Transmission: Manual

Drive Type: 4WD

Operating Weight: 1951 (ROPS), 2491 (cab)

Fuel Type: Diesel

Mitsubishi GS230 vs. Similar Tractors

Power Output
Below Average
Greater than 13% of similar tractors.
Operating Weight
Below Average
Greater than 16% of similar tractors.

Technical Specifications

Engine

Manufacturer
Mitsubishi
Model
S3L2
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
3
Displacement (ci)
80.4
Bore (in)
3.07
Stroke (in)
3.62
Rated RPM
2500
Power Output (hp)
22.7

Transmission

Type
Manual
Forward Gears
12
Reverse Gears
-
Total Gears
12

Dimensions

Length (in)
106.7
Width (in)
45.3
Height (in)
75.8 (ROPS), 109.8 (cab)
Operating Weight (lb)
1951 (ROPS), 2491 (cab)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
22
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard (ag)
Manufacture - End Year
-
Hitch Type
JIS0
Hitch Category
Category 1
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
ROPS, Cab (two options based on height)
Starter Type
Electric Starter
Brake Type
-
Hydraulic System Type
-
