Mitsubishi GS181

Last Updated: June 2024

Overview

The Mitsubishi GS181 is a compact utility tractor that comes with a robust four-wheel drive (4x4 MFWD 4WD) chassis, making it well-suited for a variety of tasks around the farm or estate. Equipped with a Mitsubishi S3L three-cylinder liquid-cooled diesel engine, it offers a power output of 17.7 horsepower at a rated RPM of 2500. The power is directed through a 12-speed transmission, providing ample range for different working conditions. The GS181 is designed for comfort with power steering, facilitating ease of maneuverability. It stands out for its ground clearance of 13.2 inches and a wheelbase of 54.3 inches. For traction in various terrain, it is typically fitted with standard agricultural tires, front-sized 6.00-12 and rear-sized 8.3-22. With an operating weight of 1819 lbs and dimensions measuring 104.3 inches in length, 43.1 inches in width, and 74.8 inches in height (with ROPS), this tractor is built to be dependable for daily tasks while offering a compact footprint.
Show more...

Key Specifications

Category: Utility

Power Output: 17.7

Drive Type: MFWD (Mechanical Front Wheel Drive)

Operating Weight: 1819

Fuel Type: Diesel

Mitsubishi GS181 vs. Similar Tractors

Power Output
Poor
Greater than 6% of similar tractors.
Operating Weight
Below Average
Greater than 14% of similar tractors.

Technical Specifications

Engine

Manufacturer
Mitsubishi
Model
S3L
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
3
Displacement (ci)
68.7
Bore (in)
3.071
Stroke (in)
3.091
Rated RPM
2500
Power Output (hp)
17.7

Transmission

Type
-
Forward Gears
12
Reverse Gears
12
Total Gears
24

Dimensions

Length (in)
104.3
Width (in)
43.1
Height (in)
74.8
Operating Weight (lb)
1819

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
MFWD (Mechanical Front Wheel Drive)
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
12
Front Tire Width (in)
-
Rear Tire Diameter (in)
22
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
JIS0
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
