Mitsubishi GS160

Last Updated: June 2024

Overview

The Mitsubishi GS160 is a compact utility tractor known for its 4x4 MFWD 4WD chassis which enhances its capability in various terrains. This model comes with a three-cylinder diesel engine from the same manufacturer, the Mitsubishi S3L, which provides a power output of 15.8 horsepower. It has a high engine-displacement of 68.7 cubic inches with a bore and stroke measuring 3.071 inches and 3.091 inches respectively, and operates at a rated RPM of 2500. The tractor is equipped with power steering and exchanges power through a 12-speed transmission, split equally between forward and reverse gears. Other notable specifications include a wheelbase of 54.3 inches, a length of 104.3 inches, a width of 42.1 inches, and a height of 73.6 inches with ROPS. Its total operating weight stands at 1808 pounds. The GS160 rides on standard agricultural tires, specified as 6-12 (front) and 8.3-20 (rear). This model provides the necessary robustness for various utility tasks in a compact framework.
Show more...

Key Specifications

Category: Utility

Power Output: 15.8

Operating Weight: 1808

Fuel Type: Diesel

Mitsubishi GS160 vs. Similar Tractors

Power Output
Poor
Greater than 4% of similar tractors.
Operating Weight
Below Average
Greater than 14% of similar tractors.

Technical Specifications

Engine

Manufacturer
Mitsubishi
Model
S3L
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally Aspirated
Cylinders
3
Displacement (ci)
68.7
Bore (in)
3.071
Stroke (in)
3.091
Rated RPM
2500
Power Output (hp)
15.8

Transmission

Type
-
Forward Gears
12
Reverse Gears
12
Total Gears
24

Dimensions

Length (in)
104.3
Width (in)
42.1
Height (in)
73.6 (with ROPS)
Operating Weight (lb)
1808

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
-
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard (ag)
Manufacture - End Year
-
Hitch Type
JIS0
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
ROPS
Starter Type
12 volts
Brake Type
-
Hydraulic System Type
-
