Mitsubishi GO321

Last Updated: June 2024

Overview

The Mitsubishi GO321 is a compact utility tractor known for its robust design and versatility. It is equipped with a 31.5 horsepower (23.5 kW) Mitsubishi S4L2, four-cylinder diesel engine. The tractor boasts a liquid-cooling system, allowing for efficient temperature management during extended work periods. Its bore and stroke measurements are 3.07 inches and 3.62 inches respectively, with an engine displacement of 107.3 cubic inches. The operating weight varies, with an option for ROPS (Rollover Protection Structure) at 3009 pounds and a cab model at 3417 pounds, depending on the operator's preference for open or enclosed working environments. The four-wheel drive (4WD) with a multi-functional MFWD chassis, combined with power steering, enhances maneuverability and handling on various terrains. It features a substantial wheelbase of 69.7 inches which contributes to stability. The transmission system, while not fully specified, offers 16 forward and reverse gears, reflecting significant versatility for a range of tasks. Dimensions for length, width, and height are provided, as well as a ground clearance of 14.4 inches, making the GO321 suitable for a variety of agricultural duties.
Show more...

Key Specifications

Category: Utility

Power Output: 31.5

Drive Type: 4WD

Operating Weight: 3009 (ROPS), 3417 (cab)

Fuel Type: Diesel

Mitsubishi GO321 vs. Similar Tractors

Power Output
Below Average
Greater than 26% of similar tractors.
Operating Weight
Below Average
Greater than 25% of similar tractors.

Technical Specifications

Engine

Manufacturer
Mitsubishi
Model
S4L2
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
107.3
Bore (in)
3.07
Stroke (in)
3.62
Rated RPM
2500
Power Output (hp)
31.5

Transmission

Type
-
Forward Gears
16
Reverse Gears
16
Total Gears
32

Dimensions

Length (in)
123.6
Width (in)
54.9 (ROPS), 56.1 (cab)
Height (in)
78.5 (ROPS), 79.1 (cab)
Operating Weight (lb)
3009 (ROPS), 3417 (cab)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard (ag)
Manufacture - End Year
-
Hitch Type
-
Hitch Category
JISI (Unknown exact category classification)
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
ROPS/Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
