Mitsubishi GO32

Last Updated: June 2024

Overview

The Mitsubishi GO32 is a compact utility tractor designed for a range of tasks on a smaller farm or estate. Its chassis is equipped with a 4x4 MFWD 4WD configuration, which, along with the power steering feature, allows for improved maneuverability and handling across various types of terrain. The tractor is powered by a reliable Mitsubishi S4L diesel engine with a displacement of 91.5 cubic inches, producing 31.5 horsepower at 2800 rpm. The engine's liquid-cooled system ensures efficient thermal management for continuous work. Its transmission offers a notable amount of 16 forward and 16 reverse gears, which significantly enhances the tractor's versatility in different working conditions. The GO32 is fitted with standard agricultural tires that provide sufficient traction. The dimensions of the tractor, including a length of 123.6 inches, a width of 56.1 inches, and a height under ROPS of 78.5 inches, outline this model's compact stature. The available operating weights hint at two configurations: one with ROPS (rollover protection structure) weighing 3020 lbs and another with a cab weighing 3461 lbs.
Show more...

Key Specifications

Category: Utility

Power Output: 31.5

Drive Type: MFWD (Mechanical Front Wheel Drive)

Operating Weight: 3020 (ROPS) / 3461 (Cab)

Fuel Type: Diesel

Mitsubishi GO32 vs. Similar Tractors

Power Output
Below Average
Greater than 26% of similar tractors.
Operating Weight
Above Average
Greater than 84% of similar tractors.

Technical Specifications

Engine

Manufacturer
Mitsubishi
Model
S4L
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
91.5
Bore (in)
3.07
Stroke (in)
3.09
Rated RPM
2800
Power Output (hp)
31.5

Transmission

Type
-
Forward Gears
16
Reverse Gears
16
Total Gears
32

Dimensions

Length (in)
123.6
Width (in)
56.1
Height (in)
78.5
Operating Weight (lb)
3020 (ROPS) / 3461 (Cab)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
MFWD (Mechanical Front Wheel Drive)
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard (ag)
Manufacture - End Year
-
Hitch Type
JISI
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
ROPS / Cab (weight indicated for both)
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
