Mitsubishi GO261

Last Updated: June 2024

Overview

The Mitsubishi GO261 is a compact utility tractor designed for various agricultural and utility tasks. It has a four-wheel drive (4WD) chassis and is powered by a Mitsubishi S4L2 diesel engine, offering a power output of 25.6 horsepower. The engine has a displacement of 107.3 cubic inches and operates at a rated RPM of 2500. The tractor features a manual transmission with 16 forward and reverse gears, offering versatility and control for various operations. The inclusion of power steering makes for easier maneuverability. It comes with standard agricultural tires, front 7-14 and rear 11.2-24, to handle different types of terrain. With a capable powertrain and a robust chassis, the GO261 is well-suited for tasks that require a compact but powerful tractor. Dimensions include a length of 123.6 inches and varying widths depending on whether it is equipped with ROPS at 54.7 inches or with a cab at 56.1 inches. The height also varies between ROPS and cab models, at 76.4 inches and 77.2 inches respectively. Ground clearance stands at a generous 12.4 inches, allowing for work in challenging conditions. The operating weight ranges from 2822 pounds for the ROPS model to 3230 pounds with the cab. The tractor's wheelbase is 63.8 inches, providing a stable base for both driving and stationary work. Overall, the GO261 represents a reliable choice within its class, capable of accommodating a range of agricultural demands.
Show more...

Key Specifications

Category: Utility

Power Output: 25.6

Transmission: Manual

Drive Type: 4WD

Operating Weight: ROPS: 2822 | Cab: 3230

Fuel Type: Diesel

Mitsubishi GO261 vs. Similar Tractors

Power Output
Below Average
Greater than 19% of similar tractors.
Operating Weight
Above Average
Greater than 83% of similar tractors.

Technical Specifications

Engine

Manufacturer
Mitsubishi
Model
S4L2
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
4
Displacement (ci)
107.3
Bore (in)
3.07
Stroke (in)
3.62
Rated RPM
2500
Power Output (hp)
25.6

Transmission

Type
Manual
Forward Gears
16
Reverse Gears
16
Total Gears
-

Dimensions

Length (in)
123.6
Width (in)
ROPS: 54.7 | Cab: 56.1
Height (in)
ROPS: 76.4 | Cab: 77.2
Operating Weight (lb)
ROPS: 2822 | Cab: 3230

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
JISI
Hitch Category
-
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
