Mitsubishi GM550

Last Updated: June 2024

Overview

The Mitsubishi GM550 is a compact utility tractor designed for a variety of agricultural tasks. It is powered by a Shibaura N4LDI-TA turbocharged diesel engine with a power output of 54.4 horsepower and a displacement of 135.2 cubic inches. The engine operates at a rated RPM of 2600 and sends power to all four wheels through a 4WD system with a 16-speed syncromesh transmission. Steering is assisted by a power steering system, enhancing maneuverability and ease of use. The tractor has a wheelbase of 78.2 inches, and it offers substantial operating weights of 4343 pounds with ROPS and 4663 pounds with a cabin, capable of supporting various attachments and implements. The tractor stands at a height of 99 inches with ROPS and 91.1 inches with the cabin. Standard tire sizing on this model is 8-18 for the front and 13.6-28 for the rear, which provides good traction and stability on varied terrains. Ground clearance is a notable 14.6 inches, which helps avoid undercarriage damage during field operations.
Show more...

Key Specifications

Category: Utility

Power Output: 54.4

Transmission: Syncromesh

Drive Type: 4WD

Operating Weight: 4343 (ROPS), 4663 (Cab)

Fuel Type: Diesel

Mitsubishi GM550 vs. Similar Tractors

Power Output
Average
Greater than 52% of similar tractors.
Operating Weight
Average
Greater than 40% of similar tractors.

Technical Specifications

Engine

Manufacturer
Shibaura
Model
N4LDI-TA
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
135.2
Bore (in)
3.307
Stroke (in)
3.937
Rated RPM
2600
Power Output (hp)
54.4

Transmission

Type
Syncromesh
Forward Gears
16
Reverse Gears
16
Total Gears
-

Dimensions

Length (in)
139.2
Width (in)
61.4
Height (in)
99 (ROPS), 91.1 (Cab)
Operating Weight (lb)
4343 (ROPS), 4663 (Cab)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
28
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
-
Hitch Category
I
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
