Mitsubishi GM500

Last Updated: June 2024

Overview

The Mitsubishi GM500 is a compact utility tractor that is suited for a variety of tasks, thanks to its robust 49.5 horsepower Shibaura N4LDI-T four-cylinder turbocharged diesel engine. Equipped with a liquid-cooling system, it is capable of delivering consistent performance at a rated RPM of 2600. The tractor features a comfortable operating environment, with the option for a ROPS or cab configuration, measuring 99 inches in height for the ROPS version and 91.1 inches for the cab version. The syncromesh transmission with 16 forward and reverse gears enhances operational efficiency, allowing for smooth transitions and adjustments to the operating speed. The 4WD capabilities, alongside the power steering, make it easy to navigate tough terrains. The tractor's weight ranges from 4332 pounds with the ROPS to 4652 pounds with the cab, contributing to good stability and effectiveness in field operations.
Show more...

Key Specifications

Category: Utility

Power Output: 49.5

Transmission: Syncromesh

Drive Type: 4WD

Operating Weight: 4332 (ROPS), 4652 (cab)

Fuel Type: Diesel

Mitsubishi GM500 vs. Similar Tractors

Power Output
Average
Greater than 47% of similar tractors.
Operating Weight
Average
Greater than 39% of similar tractors.

Technical Specifications

Engine

Manufacturer
Shibaura
Model
N4LDI-T
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
135.2
Bore (in)
3.307
Stroke (in)
3.937
Rated RPM
2600
Power Output (hp)
49.5

Transmission

Type
Syncromesh
Forward Gears
16
Reverse Gears
16
Total Gears
-

Dimensions

Length (in)
139.2
Width (in)
61.4
Height (in)
99 (ROPS), 91.1 (cab)
Operating Weight (lb)
4332 (ROPS), 4652 (cab)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard (ag)
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 1
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
