Mitsubishi GCR65

Last Updated: June 2024

Overview

The Mitsubishi GCR65 is characterized by a powerful 64.1 horsepower engine modeled S4S-DT, which is a turbocharged diesel, liquid-cooled with 4-cylinders and operates at a rated RPM of 2500. This tractor comes equipped with a hydrostatic transmission that features infinite forward and reverse gears within a 2-range setup, allowing for precise control and a range of operating speeds. The dimensions include a length of 152.8 inches, width of 70.9 inches, and a height of 101.2 inches. The stated operating weight for this model is 7981 lbs, which contributes to its stability and traction. Additionally, it has a noteworthy ground clearance of 15.4 inches and a gauge of 53.2 inches, aiding in its usability in varied terrain. Details of its hitch system suggest compatibility with JISII/JISI standards which indicates a certain robustness for towing and lifting.

Key Specifications

Power Output: 64.1

Transmission: Hydrostatic

Operating Weight: 7981

Fuel Type: Diesel

Image Gallery

Mitsubishi GCR65 Tractor

Technical Specifications

Engine

Manufacturer: Mitsubishi
Model: S4S-DT
Cooling Type: Liquid-cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Turbocharged
Cylinders: 4
Displacement (ci): 203.3
Bore (in): 3.7
Stroke (in): 4.72
Rated RPM: 2500
Power Output (hp): 64.1

Transmission

Type: Hydrostatic
Forward Gears: Infinite (2-range)
Reverse Gears: Infinite (2-range)
Total Gears: -

Dimensions

Length (in): 152.8
Width (in): 70.9
Height (in): 101.2
Operating Weight (lb): 7981

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: -
Drive Type: -
Steering Type: -
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: -
Manufacture - End Year: -
Hitch Type: JISII/JISI (Assuming a type of three-point hitch based on indicated rear type)
Hitch Category: -
Hitch Position: -
Hitch Capacity (lb): -
Operator Station Type: -
Starter Type: Electric (Implied from Starter volts data)
Brake Type: -
Hydraulic System Type: -
