Mitsubishi GCR55

Last Updated: June 2024

Overview

The Mitsubishi GCR55 is a tractor powered by a 54.3 horsepower Mitsubishi S4S four-cylinder diesel engine. The hydrostatic transmission provides an infinite number of gears within two ranges for both forward and reverse directions, allowing for greater control over the machine's output during various tasks. A significant feature of the GCR55 is the liquid-cooling system, presumably ensuring efficient heat dissipation and maintaining optimal operating temperatures. The engine's displacement is 203.3 cubic inches, with a bore and stroke of 3.70 inches and 4.72 inches respectively, and operates at a rated 2500 RPM. The tractor has an operating weight of 7385 pounds and dimensions are 149.6 inches in length, 68.9 inches in width, and 101.2 inches in height. While this description provides an overview of the tractor's power and size, details on the chassis, drive and steering types are not available.
Show more...

Key Specifications

Power Output: 54.3

Transmission: hydrostatic

Operating Weight: 7385

Fuel Type: diesel

Technical Specifications

Engine

Manufacturer
Mitsubishi
Model
S4S
Cooling Type
liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
diesel
Induction Type
-
Cylinders
4
Displacement (ci)
203.3
Bore (in)
3.7
Stroke (in)
4.72
Rated RPM
2500
Power Output (hp)
54.3

Transmission

Type
hydrostatic
Forward Gears
infinite (2-range)
Reverse Gears
infinite (2-range)
Total Gears
infinite (2-range)

Dimensions

Length (in)
149.6
Width (in)
68.9
Height (in)
101.2
Operating Weight (lb)
7385

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
JISI
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
12 volts
Brake Type
-
Hydraulic System Type
-
