Mitsubishi GAK50

Last Updated: June 2024

Overview

The Mitsubishi GAK50 is a half-track crawler tractor which is characterized by its tracked chassis design and 50 horsepower (37.3 kW) engine. It provides strong traction and stability, well-suited for working in varied and challenging terrains where standard wheeled tractors might struggle. This tractor features a liquid-cooled 4-cylinder Iseki E4DE diesel engine with a displacement of 180.3 cubic inches, rated to operate at 2500 RPM. The GAK50 has a significant transmission system boasting 32 forward and reverse gears, which provides a high level of control over speed and power during operation. The tractor is fitted with power steering, making maneuvering at low speeds or in tight spaces easier for the operator. With a wheelbase of 77.6 inches and dimensions of 143.5 inches in length and 66.3 inches in width, it acquaints itself with medium-scale tasks very well. The Mitsubishi GAK50 can be found with either a Rollover Protection Structure (ROPS) or an enclosed cab, weighing 5027 lbs and 5490 lbs, respectively. The height varies between these two options, with the ROPS being taller at 100.2 inches, likely due to safety structures extending above the operator's station. Details like hydraulic power, PTO speeds, and specific brake types were not provided. It is designed to cater to the needs of farmers requiring a robust and versatile machine that can perform a variety of tasks under different field conditions.
Show more...

Key Specifications

Category: Crawler

Power Output: 50

Drive Type: Track

Operating Weight: ROPS Weight: 5027; Cab Weight: 5490

Fuel Type: Diesel

Mitsubishi GAK50 vs. Similar Tractors

Power Output
Below Average
Greater than 29% of similar tractors.
Operating Weight
Excellent
Greater than 93% of similar tractors.

Technical Specifications

Engine

Manufacturer
Iseki
Model
E4DE
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
180.3
Bore (in)
3.82
Stroke (in)
3.94
Rated RPM
2500
Power Output (hp)
50

Transmission

Type
-
Forward Gears
32
Reverse Gears
32
Total Gears
64

Dimensions

Length (in)
143.5
Width (in)
66.3
Height (in)
Height (ROPS): 100.2; Height (cab): 91.9
Operating Weight (lb)
ROPS Weight: 5027; Cab Weight: 5490

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
half-track
Drive Type
Track
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
8.3
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural front; tracks rear
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
ROPS & Cab options available
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
