Mitsubishi GAK46

Last Updated: June 2024

Overview

The Mitsubishi GAK46 is a half-track crawler tractor with a significant historical presence in agriculture and construction sectors. With a liquid-cooled 4-cylinder Iseki E4CG diesel engine, it offers a robust power output of 45.6 hp. Its 64 total gears, including 32 forward and 32 reverse, are managed via a wet disc clutch, allowing for precise maneuvering and a range of speed settings that can suit various tasks. The power steering system aids in handling the machine even in rough terrain. This tractor has a power output of 45.6 horsepower at a rated RPM of 2500, enhancing its capacity for heavy-duty work. The tractor's substantial operating weight of 5412 lbs contributes to stability and traction. Its wheelbase stands at 76 inches while offering a ground clearance of 15.9 inches, which helps in maintaining a lower center of gravity while still being capable of crossing obstacles. The crawler's dimensions, length of 143.5 inches and width of 66.3 inches, coupled with the height of 91.9 inches, reflect its sturdy build. The Mitsubishi GAK46 serves well for those requiring a durable and powerful track option for challenging terrain and demanding tasks.
Show more...

Key Specifications

Category: Crawler

Power Output: 45.6

Operating Weight: 5412

Fuel Type: Diesel

Mitsubishi GAK46 vs. Similar Tractors

Power Output
Below Average
Greater than 25% of similar tractors.
Operating Weight
Average
Greater than 34% of similar tractors.

Technical Specifications

Engine

Manufacturer
Iseki
Model
E4CG
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
4
Displacement (ci)
134.1
Bore (in)
3.43
Stroke (in)
3.62
Rated RPM
2500
Power Output (hp)
45.6

Transmission

Type
-
Forward Gears
32
Reverse Gears
32
Total Gears
64

Dimensions

Length (in)
143.5
Width (in)
66.3
Height (in)
91.9
Operating Weight (lb)
5412

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
Half-track
Drive Type
-
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Category 1
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
