Mitsubishi GA550

Last Updated: June 2024

Overview

The Mitsubishi GA550 is a versatile and robust compact utility tractor designed to cater to various agricultural needs. It features a durable and efficient Shibaura N4LDI-TA four-cylinder turbocharged diesel engine that offers 54.4 horsepower at a rated RPM of 2600. With its liquid-cooled engine system, it assures a consistent performance under different working conditions. The tractor boasts a full-time four-wheel drive (4WD) with a 4x4 MFWD chassis configuration for improved traction and handling on uneven terrains. Users benefit from both a comfortable operating station with either ROPS or cab options and convenient power steering for easier maneuverability. The transmission system is built for heavy-duty tasks, offering 32 forward and reverse gears, operated through a wet disc clutch system. The tractor has standard ag tires, with sizes 8.3-20 in the front and 13.6-28 in the rear, and a wheelbase of 77.6 inches, contributing to its stability and grip. The Mitsubishi GA550 has a significant presence, measuring 139.6 inches in length, 66.9 inches in width, and varying heights of 98.8 inches with ROPS and 91.5 inches with the cab. It can handle a wide variety of tasks while offering operator comfort and high productivity.
Show more...

Key Specifications

Category: Utility

Power Output: 54.4

Drive Type: 4WD

Operating Weight: 4288 (ROPS), 4740 (cab)

Fuel Type: Diesel

Mitsubishi GA550 vs. Similar Tractors

Power Output
Average
Greater than 52% of similar tractors.
Operating Weight
Average
Greater than 39% of similar tractors.

Technical Specifications

Engine

Manufacturer
Shibaura
Model
N4LDI-TA
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
135.2
Bore (in)
3.31
Stroke (in)
3.94
Rated RPM
2600
Power Output (hp)
54.4

Transmission

Type
-
Forward Gears
32
Reverse Gears
32
Total Gears
64

Dimensions

Length (in)
139.6
Width (in)
66.9
Height (in)
98.8 (ROPS), 91.5 (cab)
Operating Weight (lb)
4288 (ROPS), 4740 (cab)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard (ag)
Manufacture - End Year
-
Hitch Type
Rear Type I
Hitch Category
-
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
ROPS, Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
