Mitsubishi GA500

Last Updated: June 2024

Overview

The Mitsubishi GA500 is a compact utility tractor well-suited for various tasks around smaller farms or estates. It boasts a powerful 49.5 horsepower Shibaura N4LDI-T turbocharged diesel engine that operates at 2600 RPM with a displacement of 135.2 ci. The engine's 4 cylinders ensure consistent and reliable performance, while the liquid cooling system helps maintain optimal engine temperatures. Equipped with a four-wheel-drive, MFWD 4WD chassis, and power steering, this tractor provides enhanced traction and maneuverability on different terrains. It features a robust transmission with 32 forward and reverse gears, which facilitates a wide range of speeds and a wet disc clutch for efficient operation. The large wheelbase of 77.6 inches contributes to its stability. The GA500 also offers a choice between an open station with ROPS (Roll-Over Protection Structure) or an optional cab, both providing different height dimensions and operating weights, to cater to various operator preferences and tasks.
Show more...

Key Specifications

Category: Utility

Power Output: 49.5

Drive Type: 4WD

Operating Weight: 4277 (ROPS), 4729 (cab)

Fuel Type: Diesel

Mitsubishi GA500 vs. Similar Tractors

Power Output
Average
Greater than 47% of similar tractors.
Operating Weight
Average
Greater than 39% of similar tractors.

Technical Specifications

Engine

Manufacturer
Shibaura
Model
N4LDI-T
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
135.2
Bore (in)
3.31
Stroke (in)
3.94
Rated RPM
2600
Power Output (hp)
49.5

Transmission

Type
-
Forward Gears
32
Reverse Gears
32
Total Gears
64

Dimensions

Length (in)
139.6
Width (in)
66.9
Height (in)
98.8 (ROPS), 91.5 (cab)
Operating Weight (lb)
4277 (ROPS), 4729 (cab)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
ROPS, Cab (optional)
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
