Mitsubishi GA50

Last Updated: June 2024

Overview

The Mitsubishi GA50 is a compact utility tractor designed for various types of agricultural work. It features a 50 horsepower (37.3 kW) Iseki E4DE diesel engine with a liquid-cooling system. The tractor has a 4x4 MFWD 4WD chassis and power steering, which enhances maneuverability and ease of operation. It is equipped with a 32-speed transmission that includes a wet disc clutch, offering a robust selection of gear ratios for various tasks. The GA50 has a wheelbase of 77.6 inches (197 cm) and is available with either a ROPS or a cab, influencing both operating weight and overall height. The ground clearance is a substantial 15.2 inches (38 cm), which adds to the machine's versatility. This tractor's tire configuration comes standard with agricultural tires, front sized at 8.3-20 and rear at 13.6-28. The machine's physical dimensions and weight indicate that it's capable of substantial workloads, while being of a size that ensures suitability for a range of farm and land management tasks.
Show more...

Key Specifications

Category: Utility

Power Output: 50

Drive Type: 4WD

Operating Weight: 4112 (with ROPS), 4564 (with cab)

Fuel Type: Diesel

Mitsubishi GA50 vs. Similar Tractors

Power Output
Average
Greater than 49% of similar tractors.
Operating Weight
Average
Greater than 37% of similar tractors.

Technical Specifications

Engine

Manufacturer
Iseki
Model
E4DE
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally Aspirated
Cylinders
4
Displacement (ci)
180.3
Bore (in)
3.82
Stroke (in)
3.94
Rated RPM
2500
Power Output (hp)
50

Transmission

Type
-
Forward Gears
32
Reverse Gears
32
Total Gears
64

Dimensions

Length (in)
143.5
Width (in)
66.9
Height (in)
99 (Height with ROPS), 90.6 (Height with cab)
Operating Weight (lb)
4112 (with ROPS), 4564 (with cab)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power Steering
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard (ag)
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
ROPS/Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
