Mitsubishi GA300

Last Updated: June 2024

Overview

The Mitsubishi GA300 is a compact utility tractor that offers a robust 30 horsepower output, suitable for various agricultural tasks. Equipped with a Shibaura N3LDI-T three-cylinder turbocharged diesel engine, it provides efficient power delivery, especially with its significant displacement of 101.4 cubic inches and power-rated RPM of 2600. The tractor features a mechanical four-wheel drive system with a 24-speed transmission, allowing it to handle a variety of terrains and tasks with ease. It operates on standard agricultural tires and offers the flexibility and stability needed for general farming operations. This model comes with either a ROPS or a full cabin, depending on the owner's preference, catering to safety and comfort requirements in various working conditions. Its wheelbase is 66.9 inches, with a length of 130.7 inches, and offers two height options, depending on whether it is equipped with ROPS or a cab. The GA300 can come with a category I hitch and as of the available data, it's not clear when it was first manufactured or when production ended.
Show more...

Key Specifications

Category: Utility

Power Output: 30

Drive Type: 4WD

Operating Weight: 3538 (ROPS), 3935 (Cab)

Fuel Type: Diesel

Mitsubishi GA300 vs. Similar Tractors

Power Output
Below Average
Greater than 25% of similar tractors.
Operating Weight
Average
Greater than 31% of similar tractors.

Technical Specifications

Engine

Manufacturer
Shibaura
Model
N3LDI-T
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
3
Displacement (ci)
101.4
Bore (in)
3.31
Stroke (in)
3.94
Rated RPM
2600
Power Output (hp)
30

Transmission

Type
-
Forward Gears
24
Reverse Gears
24
Total Gears
-

Dimensions

Length (in)
130.7
Width (in)
59.5
Height (in)
96.3 (ROPS), 84.7 (Cab)
Operating Weight (lb)
3538 (ROPS), 3935 (Cab)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard (ag)
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
ROPS, Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
