McCormick Intl XTX185

Last Updated: June 2024

Overview

The McCormick Intl XTX185 is a robust row-crop tractor designed for a variety of agricultural tasks. Equipped with a powerful 162 horsepower Iveco turbocharged diesel engine, it boasts a significant torque, measuring at 157.4 lb-ft. With an engine displacement of 408.8 cubic inches, the liquid-cooled six-cylinder engine can handle heavy loads and challenging farm activities. The tractor's chassis is a 4x4 MFWD 4WD, providing excellent traction in diverse terrain. The hydrostatic power steering facilitates maneuverability, and the XtraSpeed powershift transmission with 32 forward and 24 reverse gears offers a wide range of speed options for optimal performance. The tractor has a considerable size, with a length of 209 inches and height of 119 inches, and an operating weight of 17,739 pounds. Its durable construction is meant to withstand the rigorous demands of the agricultural environment.
Show more...

Key Specifications

Category: Row Crop

Power Output: 162

Transmission: XtraSpeed powershift

Drive Type: 4WD

Operating Weight: 17,739

Fuel Type: Turbocharged diesel

McCormick Intl XTX185 vs. Similar Tractors

Power Output
Average
Greater than 59% of similar tractors.
Operating Weight
Below Average
Greater than 10% of similar tractors.

Technical Specifications

Engine

Manufacturer
Iveco
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Turbocharged diesel
Induction Type
Turbocharged
Cylinders
6
Displacement (ci)
408.8
Bore (in)
4.094
Stroke (in)
5.197
Rated RPM
2200
Power Output (hp)
162

Transmission

Type
XtraSpeed powershift
Forward Gears
32
Reverse Gears
24
Total Gears
-

Dimensions

Length (in)
209
Width (in)
-
Height (in)
119
Operating Weight (lb)
17,739

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
III
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric Starter (assumed from mention of starter volts)
Brake Type
-
Hydraulic System Type
PFC
