McCormick Intl MTX200

Last Updated: June 2024

Overview

The McCormick Intl MTX200 is a row-crop tractor known for its robust power and versatility. It is equipped with a powerful Cummins QSB turbocharged diesel engine, capable of delivering 204 horsepower and 590 lb-ft of torque, to handle a range of demanding agricultural tasks. With a 4x4 MFWD 4WD chassis and hydrostatic power steering, the MTX200 offers substantial maneuverability in various field conditions. Its powershift transmission comes with 32 forward and 24 reverse gears, facilitating efficient operations in multiple applications. The tractor has a substantial operating weight of 17,000 lbs, ensuring stability and traction. The wheelbase of 112.99 inches contributes to a balanced and comfortable ride during extended usage. Additional specifications such as size and type of tires indicate its suitability for a variety of terrains, with front and rear tires designed for agricultural purposes. While some specifics concerning dimensions and capabilities may be unknown, the MTX200 remains a capable machine for row-crop farming.
Show more...

Key Specifications

Category: Row Crop

Power Output: 204

Transmission: Powershift

Drive Type: 4WD

Operating Weight: 17000

Fuel Type: Diesel

McCormick Intl MTX200 vs. Similar Tractors

Power Output
Above Average
Greater than 74% of similar tractors.
Operating Weight
Average
Greater than 64% of similar tractors.

Technical Specifications

Engine

Manufacturer
Cummins
Model
QSB
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
24-valve
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
6
Displacement (ci)
359
Bore (in)
4.02
Stroke (in)
4.72
Rated RPM
2200
Power Output (hp)
204

Transmission

Type
Powershift
Forward Gears
32
Reverse Gears
24
Total Gears
-

Dimensions

Length (in)
205.91
Width (in)
-
Height (in)
-
Operating Weight (lb)
17000

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural (AG)
Manufacture - End Year
-
Hitch Type
-
Hitch Category
III
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric (12 volts)
Brake Type
-
Hydraulic System Type
Pressure flow compensating
