McCormick Intl MTX165

Last Updated: June 2024

Overview

The McCormick Intl MTX165 is a turbocharged diesel, 6-cylinder, liquid-cooled, row-crop tractor designed to meet the needs of the contemporary farmer. With a powerful 160 hp Iveco engine and large displacement of 411.88 ci, it provides substantial torque for various agricultural tasks. This particular model features an advanced powershift transmission with 32 forward and 24 reverse gears, facilitating adequate speed changes for both field and transport operations. Hydrostatic power steering and a weight of 16,185 lbs combine to offer steady and comfortable maneuvering. The tractor is fitted with a Category 3, three-point hitch at the rear, suitable for a wide range of implements. Despite its focus on raw power and capability, the MTX165 leaves some details to the imagination, as further specifics on its size, tire measurements, and PTO among others remain undisclosed.
Show more...

Key Specifications

Category: Row Crop

Power Output: 160

Transmission: powershift

Drive Type: 4WD

Operating Weight: 16,185

Fuel Type: diesel

McCormick Intl MTX165 vs. Similar Tractors

Power Output
Average
Greater than 59% of similar tractors.
Operating Weight
Poor
Greater than 10% of similar tractors.

Technical Specifications

Engine

Manufacturer
Iveco
Model
-
Cooling Type
liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
diesel
Induction Type
turbocharged
Cylinders
6
Displacement (ci)
411.88
Bore (in)
4.094
Stroke (in)
5.197
Rated RPM
2200
Power Output (hp)
160

Transmission

Type
powershift
Forward Gears
32
Reverse Gears
24
Total Gears
-

Dimensions

Length (in)
205.91
Width (in)
-
Height (in)
-
Operating Weight (lb)
16,185

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag front: Radial
Manufacture - End Year
-
Hitch Type
III
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric, 12 volts
Brake Type
-
Hydraulic System Type
pressure flow compensating
