McCormick Intl MTX145

Last Updated: June 2024

Overview

The McCormick Intl MTX145 is a robust agriculture tractor sporting a 4WD chassis configuration with Mechanical Front Wheel Drive (MFWD). This model is equipped with a 6-cylinder liquid-cooled turbocharged diesel engine possessing a displacement of 410.6 cubic inches that delivers 133 horsepower and a remarkable torque of 435 lb-ft at a low 1250 RPM, highlighting the tractor's substantial pulling power. The engine's operating peak stretches up to 2200 RPM. For transmission, it features a versatile partial power shift system that provides 32 forward and 24 reverse gears, facilitating a variety of tasks and conditions with ease. The tractor's length measures 203 inches, with a width of 90 inches and a cab height of 114 inches, offering a substantial working presence. The MTX145 weighs in at 11,905 pounds and has a wheelbase of 107 inches, which gives it stability and support during heavy-duty operations.
Show more...

Key Specifications

Power Output: 133

Transmission: Partial Power Shift

Drive Type: 4WD

Operating Weight: 11,905

Fuel Type: Diesel

Technical Specifications

Engine

Manufacturer
McCormick Intl
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
6
Displacement (ci)
410.6
Bore (in)
-
Stroke (in)
-
Rated RPM
2200
Power Output (hp)
133

Transmission

Type
Partial Power Shift
Forward Gears
32
Reverse Gears
24
Total Gears
-

Dimensions

Length (in)
203
Width (in)
90
Height (in)
114
Operating Weight (lb)
11,905

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag front: 420/85R28, Ag rear: 520/85R38
Manufacture - End Year
-
Hitch Type
IIIN (3-point hitch)
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
-
Brake Type
-
Hydraulic System Type
-
