McCormick Intl MTX110

Last Updated: June 2024

Overview

The McCormick Intl MTX110 is a robust row-crop tractor powered by a turbocharged, Perkins 1006-60T, six-cylinder diesel engine with a liquid cooling system. It affords ample power, generating 116 horsepower and a substantial torque output of 343 lb-ft at a low 1400 RPM, suitable for demanding farm tasks. It features a mechanical front-wheel-drive system (MFWD) with a hydrostatic power steering that allows easier maneuverability in the field. The tractor's transmission is a versatile arrangement, offering a four-speed power shift with a creeper option, which gives a total of 32 forward gears and 24 reverse gears to tackle a variety of operations with optimal control over speed. The MTX110 stands on a strong chassis with a wheelbase of 270 cm (106.3 inches), providing stability across varied terrain. It is large in size, with a total length of 516 cm (203.2 inches), a width of 230 cm (90.6 inches), and has a cab height of 288 cm (113.4 inches). The tractor comes equipped with a Category II three-point hitch at the rear and has an operating weight of 11900 lbs. This workhorse is built for durability and performance in the demanding row-crop sector.
Show more...

Key Specifications

Category: Row Crop

Power Output: 116

Transmission: Four-speed power shift with creeper option

Drive Type: MFWD (Mechanical Front Wheel Drive)

Operating Weight: 11900 (shipping weight)

Fuel Type: Diesel

McCormick Intl MTX110 vs. Similar Tractors

Power Output
Average
Greater than 33% of similar tractors.
Operating Weight
Average
Greater than 46% of similar tractors.

Technical Specifications

Engine

Manufacturer
Perkins
Model
1006-60T
Cooling Type
Liquid-cooled
Cylinder Orientation
Vertical
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
6
Displacement (ci)
365
Bore (in)
3.937
Stroke (in)
5
Rated RPM
2200
Power Output (hp)
116

Transmission

Type
Four-speed power shift with creeper option
Forward Gears
32 (Including creeper gears)
Reverse Gears
24 (Including creeper gears)
Total Gears
-

Dimensions

Length (in)
203.2
Width (in)
90.6
Height (in)
113.4 (Height of cab)
Operating Weight (lb)
11900 (shipping weight)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
MFWD (Mechanical Front Wheel Drive)
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
Unknown (Spec provided is tire size, not diameter)
Front Tire Width (in)
Unknown (Spec provided is tire size, not width)
Rear Tire Diameter (in)
Unknown (Spec provided is tire size, not diameter)
Rear Tire Width (in)
Unknown (Spec provided is tire size, not width)
Front/Rear Rim Diameter (in)
-
Tire Type
Ag (Agricultural)
Manufacture - End Year
-
Hitch Type
Three-point hitch
Hitch Category
II
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
-
Brake Type
-
Hydraulic System Type
Pressure flow compensating
