McCormick Intl MC95

Last Updated: June 2024

Overview

The McCormick Intl MC95 is a utility tractor that is engineered for versatility and durability, suitable for a variety of farming tasks. With its Perkins 1104C-44T turbocharged diesel engine, it delivers a power output of 90 hp and a peak torque of 286 lb-ft at 1400 RPM. The engine operates at a rated RPM of 2200 and features liquid-cooling to maintain performance under different working conditions. The chassis is designed as 4x2 2WD, equipped with hydrostatic power steering for enhanced maneuverability. The tractor's transmission is a partial power shift type, providing 32 forward and 24 reverse gears, allowing operators to select the optimum speed for different tasks with ease. It sits on a 94.5-inch wheelbase and has a ground clearance of 14 inches, measures 169 inches in length and 77 inches in width, and has an operational weight ranging from 9610 to 11905 pounds, which supports stable and robust performance. Equipped with pressure flow compensated hydraulics, the MC95 caters to various implements and attachments, augmenting its utility on the farm.
Show more...

Key Specifications

Category: Utility

Power Output: 90

Transmission: Partial power shift

Drive Type: 2WD

Operating Weight: 9610 to 11905

Fuel Type: Diesel

McCormick Intl MC95 vs. Similar Tractors

Power Output
Above Average
Greater than 77% of similar tractors.
Operating Weight
Excellent
Greater than 93% of similar tractors.

Technical Specifications

Engine

Manufacturer
Perkins
Model
1104C-44T
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
268
Bore (in)
4.134
Stroke (in)
5
Rated RPM
2200
Power Output (hp)
90

Transmission

Type
Partial power shift
Forward Gears
32
Reverse Gears
24
Total Gears
-

Dimensions

Length (in)
169
Width (in)
77
Height (in)
-
Operating Weight (lb)
9610 to 11905

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
Pressure flow compensated
