McCormick Intl GX45

Last Updated: June 2024

Overview

The McCormick Intl GX45 is a versatile compact utility tractor powered by a 44 horsepower Yanmar diesel engine with a displacement of 121.7 cubic inches. Designed with either a two-wheel drive or four-wheel drive chassis, it features hydrostatic power steering for ease of handling and offers multiple transmission options including hydrostatic, synchronized shuttle, and a synchronized shuttle with creeper option, providing a range of speeds for various tasks. This model is capable of operating with standard agricultural tires, and the tractor's length measures 134.7 inches with a width of 54.3 inches. Depending on configuration, the GX45 weighs between 3197 to 3483 pounds. The tractor also includes a Category I hitch, a 12-volt electric starter, and an open center hydraulic system.
Show more...

Key Specifications

Category: Utility

Power Output: 44

Transmission: Hydrostatic; Synchronized shuttle; Synchronized shuttle with creeper

Drive Type: 2WD or 4WD

Operating Weight: 2WD Shuttle: 3197; 4WD Shuttle: 3373; 2WD Hydro: 3307; 4WD Hydro: 3483

Fuel Type: Diesel

Image Gallery

McCormick Intl GX45 Tractor McCormick Intl GX45 Tractor McCormick Intl GX45 Tractor McCormick Intl GX45 Tractor McCormick Intl GX45 Tractor McCormick Intl GX45 Tractor

McCormick Intl GX45 vs. Similar Tractors

Power Output
Average
Greater than 41% of similar tractors.
Operating Weight
Excellent
Greater than 100% of similar tractors.

Technical Specifications

Engine

Manufacturer
Yanmar
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Direct injection
Cylinders
4-cylinder
Displacement (ci)
121.7
Bore (in)
3.3071
Stroke (in)
3.54
Rated RPM
2800
Power Output (hp)
44

Transmission

Type
Hydrostatic; Synchronized shuttle; Synchronized shuttle with creeper
Forward Gears
-
Reverse Gears
-
Total Gears
Infinite (3-range) for the hydrostatic variant; 12 for the synchronized shuttle; 16 for the shuttle with creeper

Dimensions

Length (in)
134.7
Width (in)
54.3
Height (in)
Steering wheel: 57.1; ROPS: 91.9
Operating Weight (lb)
2WD Shuttle: 3197; 4WD Shuttle: 3373; 2WD Hydro: 3307; 4WD Hydro: 3483

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD or 4x4 4WD
Drive Type
2WD or 4WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard tires (ag): Front: 280/70R16, Rear: 340/65R28; Optional (4WD): Front: 270/70R16, Rear: 340/65R28
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
12-volt
Brake Type
-
Hydraulic System Type
Open center
