McCormick Intl GM55

Last Updated: June 2024

Overview

The McCormick Intl GM55 is a compact utility tractor that boasts a robust 4-cylinder turbocharged Yanmar diesel engine with a displacement of 121.7 cubic inches. This liquid-cooled engine, model 4TNV84T, achieves a power output of 54.2 horsepower at 2800 RPM, and delivers a torque of 117.6 lb-ft at just 1200 RPM with a compression ratio of 18.9:1. Designed to meet Tier III emissions standards, it ensures a balance between power and environmental considerations. It features a versatile 4WD chassis and a creeper transmission with 16 forward and reverse gears, providing ample flexibility for various tasks. The tractor's dimensions include a length of 132.3 inches, a width of 55 inches, and a wheelbase of 69.3 inches, allowing for stable operation in varied conditions. The tractor's weight is listed at 3263 lbs, and while the exact height is not provided, the presence of ROPS and possible cab options suggest a range of configurations to suit operator preferences. This model is designed to accommodate a variety of attachments and implements, thanks to the Category I rear hitch. This tractor is a workhorse suited for a range of tasks on the farm, orchard, or in other settings where compact utility vehicles are prized.
Show more...

Key Specifications

Category: Utility

Power Output: 54.2

Transmission: Creeper

Drive Type: 4WD

Operating Weight: 3263

Fuel Type: Diesel

McCormick Intl GM55 vs. Similar Tractors

Power Output
Average
Greater than 52% of similar tractors.
Operating Weight
Below Average
Greater than 28% of similar tractors.

Technical Specifications

Engine

Manufacturer
Yanmar
Model
4TNV84T
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
16-valve
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
121.7
Bore (in)
3.307
Stroke (in)
3.543
Rated RPM
2800
Power Output (hp)
54.2

Transmission

Type
Creeper
Forward Gears
16
Reverse Gears
16
Total Gears
-

Dimensions

Length (in)
132.3
Width (in)
55
Height (in)
Unknown (ROPS: 77.2 | Cab: 85.4)
Operating Weight (lb)
3263

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Unknown (Presence of ROPS and Cab suggests options available)
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
