McCormick Intl C60

Last Updated: June 2024

Overview

The McCormick Intl C60 is a utility tractor equipped with a robust Perkins turbocharged diesel engine. It is well-suited for a variety of tasks on the farm or field, thanks to its 64 horsepower engine and a displacement of 164.75 cubic inches. The tractor operates with a liquid-cooled system to maintain optimum engine temperature even under heavy loads. Transmission-wise, it sports a synchromesh with 16 forward and 8 reverse gears. The tractor stands out for its 4x2 2WD chassis configuration, which suggests better maneuverability on hard surfaces and suitability for general-purpose farming tasks. With a broad weight range between 5358 and 6096 pounds, depending on configuration, the C60 can handle multiple attachments and implements with its category 3 hitch, though specific lift capacities are unknown. Details about the tractor's dimensions, tires, and starter type are not specified, but its operating weight indicates it's a mid-size tractor with significant capabilities.
Show more...

Key Specifications

Category: Utility

Power Output: 64

Transmission: Synchromesh

Drive Type: 2WD

Operating Weight: 5358 to 6096

Fuel Type: Diesel

McCormick Intl C60 vs. Similar Tractors

Power Output
Average
Greater than 60% of similar tractors.
Operating Weight
Above Average
Greater than 88% of similar tractors.

Technical Specifications

Engine

Manufacturer
Perkins
Model
-
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
3
Displacement (ci)
164.75
Bore (in)
3.74
Stroke (in)
5
Rated RPM
2250
Power Output (hp)
64

Transmission

Type
Synchromesh
Forward Gears
16
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
-
Width (in)
-
Height (in)
-
Operating Weight (lb)
5358 to 6096

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
Open Center
