McCormick-Deering Super AWD-6

The McCormick-Deering Super AWD-6 is a standard-tread tractor manufactured by McCormick-Deering, a part of International Harvester. It features a 4x2 two-wheel drive chassis with a manual 5-speed transmission that offers 5 forward gears and 1 reverse gear. The tractor is powered by a 4-cylinder International Harvester diesel engine, boasting a displacement of 264 cubic inches and operating at a rated speed of 1450 RPM. The liquid cooling system holds up to 20 quarts, ensuring proper temperature regulation during operation. With a length of 125 inches, a width of 72.75 inches, and a height of 91.5 inches to the top of the exhaust, the Super AWD-6 presents a considerable presence in the field. It has a wheelbase of 76.5 inches and provides ground clearance of 15.1 inches at the rear axle. The Super AWD-6 is built for durability and heavy tasks with an operating weight of 7298 pounds. Key features include electric starting and glow plugs for easy start-up of the diesel engine, especially in cold weather conditions. Although the tractor's exact horsepower rating and PTO details are not provided, users can expect sturdy performance consistent with the needs of its time for various agricultural applications. The tractor's tire configuration with Ag front 7.50-16 and Ag rear 14x30 tires supports its use in a range of field conditions.
