McCormick-Deering B-450

Last Updated: June 2024

Overview

The McCormick-Deering B-450 is a standard-tread tractor known for its durable build and versatility. Featuring a 4x2 2WD chassis and manual steering, it is equipped with a 5-speed gear transmission that provides adequate range for various tasks. The B-450 operates with a 55 hp International Harvester BD-264 diesel engine, boasting a 264 ci displacement, a bore and stroke of 4.00x5.25 inches, and a rated RPM of 1500. For cooling, it uses a liquid system with a 26.4 qt capacity. As for its operating characteristics, the tractor weighs in at 6020 lbs in its 2WD form, with a length of 131.2 inches and a steering wheel height of 71 inches, showcasing a robust stature suitable for a variety of farming needs. Its grip on the terrain is ensured by agricultural front tires of 6.00x16 and rear tires of 13.00x30. The McCormick-Deering B-450 remains an efficient choice for farmers needing a dependable and straightforward tractor for their agricultural operations.
Show more...

Key Specifications

Category: Utility, Standard Tread

Power Output: 55 hp

Transmission: Gear

Drive Type: 2WD

Operating Weight: 6020 lbs (2WD)

Fuel Type: Diesel

McCormick-Deering B-450 vs. Similar Tractors

Power Output
Average
Greater than 53% of similar tractors.
Operating Weight
Above Average
Greater than 78% of similar tractors.

Technical Specifications

Engine

Manufacturer
International Harvester
Model
BD-264
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
4
Displacement (ci)
264 ci
Bore (in)
4.00 inches
Stroke (in)
5.25 inches
Rated RPM
1500
Power Output (hp)
55 hp

Transmission

Type
Gear
Forward Gears
5
Reverse Gears
1
Total Gears
-

Dimensions

Length (in)
131.2 inches (2WD)
Width (in)
-
Height (in)
71 inches (2WD, steering wheel height)
Operating Weight (lb)
6020 lbs (2WD)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Manual
Coolant Capacity (qts)
26.4 qts
Front Tire Diameter (in)
16 in (smallest listed)
Front Tire Width (in)
6.00 in (narrowest listed)
Rear Tire Diameter (in)
30 in (smallest listed)
Rear Tire Width (in)
13.00 in (narrowest listed)
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
Category II
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open Center
