McCormick-Deering 45585

Last Updated: June 2024

Overview

The McCormick-Deering 10-20 is a 2WD standard-tread tractor manufactured by McCormick-Deering, a part of International Harvester, from 1923 to 1939. It features a 4.6 L four-cylinder kerosene engine with a valve-in-head configuration, liquid-cooled, and delivering 20 HP at 1000 RPM. The tractor is equipped with a manual steering system and an unsynchronized gear transmission with 3 forward gears and 1 reverse. It runs on steel Agricultural tires and offers an open operator station for handling the tasks at hand. Its robust design and simple operation made it well-suited for a variety of agricultural applications during its time.
Show more...

Key Specifications

Category: Utility, Standard Tread

Power Output: 20

Transmission: Unsynchronized gear

Drive Type: 2WD

Operating Weight: 3700

Fuel Type: Kerosene

McCormick-Deering 45585 vs. Similar Tractors

Power Output
Poor
Greater than 10% of similar tractors.
Operating Weight
Average
Greater than 32% of similar tractors.

Technical Specifications

Engine

Manufacturer
International Harvester
Model
International Harvester
Cooling Type
Liquid-cooled
Cylinder Orientation
Vertical
Valve Configuration
Valve-in-head
Fuel Type
Kerosene
Induction Type
Naturally aspirated
Cylinders
4
Displacement (ci)
283.7
Bore (in)
4.25
Stroke (in)
5
Rated RPM
1000
Power Output (hp)
20

Transmission

Type
Unsynchronized gear
Forward Gears
3
Reverse Gears
1
Total Gears
-

Dimensions

Length (in)
123
Width (in)
60
Height (in)
62
Operating Weight (lb)
3700

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD
Drive Type
2WD
Steering Type
Manual
Coolant Capacity (qts)
36
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Steel (Ag)
Manufacture - End Year
1939
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Open operator station
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
